P. 404
19 VALVOLE E DISTRIBUTORI
SPECIAL VALVES
3383K 3381KSX
Valvola termostatizzabile mono/ Valvola termostatizzabile
bitubo cromata “DUAL” con mono/bitubo cromata “DUAL”
ingresso acqua reversibile e a squadra con ingresso acqua
sonda metallica di lunghezza 15 reversibile e sonda metallica
cm. Interasse attacchi 38 mm di lunghezza 15 cm. Interasse
Chrome-plated single/double attacchi 38 mm
pipe thermostatic option Angle chrome-plated single/
valve “DUAL” with reversable double pipe thermostatic option
flow inlet and metallic probe valve “DUAL” with reversable
L= 15 cm. Distance between flow inlet and metallic probe
connections 38 mm. L= 15 cm. Distance between
connections 38 mm.
24x19 fil.
18 24x19 fil.
18
Codice Tipo Attacchi Prezzo € Conf.
Code Size Connections Price € Unit/Box con volantino di comando a sinistra/ with control handwheel on the left
338 0002 G 1/2” 24 x 19 fil (ø18) 1/20 Codice Tipo Attacchi Prezzo € Conf.
Code Size Connections Price € Unit/Box
3383K ESEMPIO DI UTILIZZO 338 0028 G 1/2” 24 x 19 fil (ø18) 1/20
HOW TO USE
3381KDX
Valvola termostatizzabile
mono/ bitubo cromata “DUAL”
MONOTUBO a squadra con ingresso acqua
SINGLE PIPE reversibile e sonda metallica
di lunghezza 15 cm. Interasse
attacchi 38 mm. (con volantino
di comando a destra )
Angle chrome-plated single/
double pipe thermostatic option
valve “DUAL” with reversable
flow inlet and metallic probe
L= 15 cm. Distance between
connections 38 mm.
24x19 fil.
18
con volantino di comando a destra/ with control handwheel on the right
Codice Tipo Attacchi Prezzo € Conf.
Code Size Connections Price € Unit/Box
BITUBO
DOUBLE PIPE 338 0038 G 1/2” 24 x 19 fil (ø18) 1/20
384 For pricelist scan the QR code
