P. 407
19 VALVOLE E DISTRIBUTORI
SPECIAL VALVES
3370K 3371K
Distributore con attacchi per Distributore con attacchi per
tubi dal pavimento con portata tubi dalla parete con portata al
al radiatore 50%. Attacchi 24x19 radiatore 50%. Attacchi 24x19
fil (Ø18) con interasse 38 mm (Ø18) con interasse 38 mm per
per tubi dal pavimento. Attacco tubi dalla parete. Attacco per
per tubo rame Ø15 al radiatore tubo rame Ø15 al radiatore
Distributor for pipes from the Distributor for pipes from the
floor. Flow rate to the radiator wall. Flow rate to the radiator
50%. Single pipe 24x19 tpi 50%. Single pipe 24x19 tpi
(Ø18) connection for floor pipes. (Ø18) connection for wall pipes.
Distance between centres 38 Distance between centres 38
mm Copper pipe connection Ø15 mm. Copper pipe connection
to the radiator Ø15 to the radiator
24x19 fil. 24x19 fil.
18 18
Codice Tipo Attacchi Prezzo € Conf. Codice Tipo Attacchi Prezzo € Conf.
Code Size Connections Price € Unit/Box Code Size Connections Price € Unit/Box
337 0003 G 1/2” 24 x 19 fil (ø18) 5/25 337 0005 G 1/2” 24 x 19 fil (ø18) 5/25
3375K 3376K
Distributore con attacchi per Distributore con attacchi per
tubi dal pavimento con portata tubi dalla parete con portata al
al radiatore 100%. Attacchi radiatore 100%. Attacchi 24x19
24x19 fil (Ø18) con interasse (Ø18) con interasse 38 mm per
38 mm per tubi dal pavimento. tubi dalla parete. Attacco per
Attacco per tubo rame Ø15 al tubo rame Ø15 al radiatore
radiatore Distributor for pipes from the
Distributor for pipes from the wall. Flow rate to the radiator
floor. Flow rate to the radiator 100%. Double pipe 24x19 tpi
100%. Double pipe 24x19 tpi (Ø18) connection for wall pipes.
(Ø18) connection for floor pipes. Distance between centres 38
Distance between centres 38 mm. Copper pipe connection
mm. Copper pipe connection Ø15 to the radiator
Ø15 to the radiator
24x19 fil.
24x19 fil. 18
18
Codice Tipo Attacchi Prezzo € Conf.
Codice Tipo Attacchi Prezzo € Conf. Code Size Connections Price € Unit/Box
Code Size Connections Price € Unit/Box 337 0006 G 1/2” 24 x 19 fil (ø18) 5/25
337 0002 G 1/2” 24 x 19 fil (ø18) 5/25
387
