P. 409
19 DISTRIBUTORI BITUBO
DOUBLE PIPES DISTRIBUTORS
3391 3391BY
Distributore bitubo per piastre Distributore bitubo per piastre
convettrici con gruppo valvola convettrici con gruppo valvola
termostatica incorporato. termostatica incorporato e
Attacchi per tubo da pavimento by-pass. Attacchi per tubo da
e raccordi per piastra da 3/4”x18 pavimento e raccordi per piastra
(Eurocono) 3/4”x18(Eurocono)
Straight valve 3/4” for two-pipe Straight valve with by-pass
systems steel panel radiators 3/4” for two- pipe systems
with thermostatic valve group steel panel radiators with
3/4”x18 (Euroconus). Radiator thermostatic valve group
connection 3/4”x18 (Euroconus). Radiator
connection
3/4” 24x19 fil.
18 18 3/4” 24x19 fil.
18 18
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box CON BY-PASS/ WITH BY-PASS
339 0001 3/4” F - 3/4”(ø18) 15/45 Codice Tipo Prezzo € Conf.
339 0010 3/4” F - 24 x 19 fil (ø18) 15/45 Code Size Price € Unit/Box
339 0007 3/4” F - 3/4”(ø18) 10/30
versione nichelata/ nickel-plated version
versione cromata/ chrome-plated version 339 0006 3/4” F - 24 x 19 fil (ø18) 10/30
versione nichelata/ nickel-plated version
versione cromata/ chrome-plated version
3393
Distributore bitubo per piastre
convettrici con gruppo valvola 3393BY
termostatica incorporato. Distributore bitubo per piastre
Attacchi per tubo da parete e convettrici con gruppo valvola
raccordi per piastra da 3/4”x18 termostatica incorporato e
(Eurocono) by-pass. Attacchi per tubo da
Angle valve 3/4” for two-pipe parete e raccordi per piastra da
systems steel panel radiators 3/4”x18 Eurocono
with thermostatic valve group
3/4”x18 (Euroconus). Radiator Angle valve with by-pass
connection 3/4” for two-pipe systems
steel panel radiators with
3/4” 24x19 fil. thermostatic valve group
18 18 3/4”x18 (Euroconus). Radiator
connection
3/4” 24x19 fil.
18 18
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box
339 0002 3/4” F - 3/4”(ø18) 10/30
339 0004 3/4” F - 24 x 19 fil (ø18) 10/30 CON BY-PASS/ WITH BY-PASS
Codice Tipo Prezzo € Conf.
versione nichelata/ nickel-plated version Code Size Price € Unit/Box
versione cromata/ chrome-plated version 339 0011 3/4” F - 3/4”(ø18) 10/30
3391 - 3393 ESEMPIO DI UTILIZZO 339 0005 3/4” F - 24 x 19 fil (ø18) 10/30
HOW TO USE
versione nichelata/ nickel-plated version
versione cromata/ chrome-plated version
3390RID
Riduzione per attacchi 1/2”
femmina
Adaptor for radiators with 1/2”
female connections
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box
339 0003 3/4” x 1/2” 10/250
