P. 414
20 COPPIA COLLETTORI “FLOOR” IN OTTONE CON BY-PASS DIFFERENZIALE- 1”
“FLOOR” COUPLE OF FORGED BRASS MANIFOLDS WITH DIFFERENTIAL BY-PASS - 1”
Utilizzabili con cassetta 1939 (pag. 408)
Use with box 1939 (pag. 408)
3873JBYD DETTAGLIO BY-PASS DIFERENZIALE
Collettore di distribuzione da DETAIL DIFFERENTIAL BY-PASS
1” con by-pass differenziale e
flussimetri
1” distribution manifolds with
differential by-pass and flow
meters
3/4”
18
Con by-pass differenziale
With differential by-pass
Codice Tipo Vie Prezzo € Conf.
Code Size Ways Price € Unit/Box
385 0255 1”G 2 1/1
385 0256 1”G 3 1/1
385 0257 1”G 4 1/1
385 0258 1”G 5 1/1
385 0259 1”G 6 1/1
385 0260 1”G 7 1/1
385 0261 1”G 8 1/1
385 0262 1”G 9 1/1
385 0263 1”G 10 1/1
385 0264 1”G 11 1/1
385 0265 1”G 12 1/1
385 0268 1”G 13 1/1
385 0269 1”G 14 1/1
394 For pricelist scan the QR code
