BAMPI
Sistema di scarico POLO-KAL NG SCARICO IDRICO 43

NGSW Curva tecnica con morsetto

Codice DN D DN D1 mm. L mm. M mm. Peso Kg./pz. Conf. Pezzi Conf. Bancale €/Pz.
NGSW0301 2360 32 46x32 76,0 31,0 0,05 20 1200 7,00
NGSW0401 2361 40 46x32 79,0 31,0 0,06 20 1200 7,00
NGSW0404 2362 40 46x40 79,0 29,0 0,05 20 1200 7,00
POLO-KAL NG
NGSW0501 2363 50 46x32 88,0 30,0 0,07 20 800 7,00
NGSW0505 2364 50 46x40 88,0 26,0 0,06 20 800 7,00
NGSW0502 2365 50 67x50 89,0 29,0 0,09 20 800 7,00

NGSWPR Curva tecnica prolungata con morsetto

Codice DN OD 1 e 2 DN ODI L1 mm. L2 mm. Peso Kg./pz. Conf. Pezzi Conf. Bancale €/Pz.
NGPR0401 2250 40/50 46x32 203,0 160,0 0,15 10 400 8,20
NGPR0404 2251 40/50 46x40 203,0 160,0 0,14 10 400 8,20
NGPR0502 2252 50 67x50 203,0 160,0 0,19 10 240 8,20

POLO ASV Collare antisfilamento per sistema POLO-KAL NG

Codice DN D B max mm. L mm. Resistenza Pressione Peso Kg./pz. Conf. Pezzi €/Pz.
sfilamento massima interna
NGANTI32 1750 32 50,0 63,0 21,0 100 Kg. 2,5 bar 0,03 10 6,50
NGANTI40 1751 40 61,0 73,0 24,0 100 Kg. 2,5 bar 0,04 10 7,00
NGANTI50 1752 50 76,0 92,0 28,0 100 Kg. 2,5 bar 0,05 10 9,00
NGANTI75 1753 75 99,0 116,0 30,0 130 Kg. 2,5 bar 0,06 10 11,00
NGANTI90 1754 90 115,0 132,0 32,0 130 Kg. 2,0 bar 0,11 10 12,50
NGANTI11 1755 110 138,0 153,0 37,0 180 Kg. 2,0 bar 0,15 10 19,00
NGANTI12 1756 125 158,0 196,0 39,0 440 Kg. 2,0 bar 0,23 10 41,00
NGANTI16 1757 160 197,0 234,0 43,0 550 Kg. 2,0 bar 0,30 10 54,00
NGANTI20 1758 200 243,0 281,0 67,0 650 Kg. 1,5 bar 0,53 5 94,00
NGANTI25 1759 250 306,0 345,0 87,0 650 Kg. 1,0 bar 0,93 5 147,00

Catalogo Listino Prezzi 01/2024 Su ordinazione
