12 RACCORDI A COMPRESSIONE PER TUBO MULTISTRATO “AL-COBRAPEX”
COMPRESSION FITTINGS FOR MULTILAYER PIPE “AL-COBRAPEX”
1610 1476
Raccordo a croce nichelato Porta gomma per tubi
Cross fitting nickel-plated multistrato
Pipe support for multilayer-pipe
Codice Tipo Prezzo € Conf. Art. 1476 è obbligatorio per l’utilizzo dei raccordi serie 1600 per il tubo
Code Size Price € Unit/Box multistrato Ø40, Ø50 e Ø63 mm/ The art.1476 is mandatory for the use
of fittings 1600 series for Ø40, Ø50 and Ø63 mm multilayer pipe.
160 0136 14 x 14 x 14 x 14 5/50 “Misura” si riferisce alle dimensioni del tubo
“Size” is referred to the pipe dimensions ring
160 0071 16 x 16 x 16 x 16 5/50
Codice Misura Prezzo € Conf.
160 0121 18 x 18 x 18 x 18 5/40 Code Size Price € Unit/Box
340 0067 40 x 3,5 10/60
160 0088 20 x 20 x 20 x 20 5/40
340 0080 50 x 4,0 5/30
340 0087 63 x 4,5 1/25
1611
Tappo terminale nichelato
End cap nickel-plated H9300
O-ring
O-ring
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box
160 0083 16 10/100
Codice Tipo Prezzo € Conf.
160 0102 20 5/100 Code Size Price € Unit/Box
160 0191 25 5/50 040 0132 14 250/1500
040 0100 16 250/1500
040 0134 18 250/1500
1611GN 040 0101 20 250/1500
Tappo terminale giallo nichelato 040 0102 25-26 250/1500
End cap yellow nickel-plated 040 0103 32 250/1500
1416
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box Ogiva in ottone
160 0264 16 10/100 Brass compression ring
160 0265 20 5/100
1481 Codice Tipo Prezzo € Conf.
Code
Price €
Size
Unit/Box
Staffa per curve flangiate 140 0634 14 50/2500
Bracket for wallplate elbow
140 0159 16 50/2300
Per 1606 - 1626 140 0236 18 50/1000
For 1606 - 1626 140 0204 20 50/1200
Codice Tipo Prezzo € Conf. 140 0225 25 50/800
Code Size Price € Unit/Box 140 0637 26 50/800
147 0005 unica/ single 1/100
140 0220 32 10/400
