P. 249
RACCORDI A PRESSARE PER TUBO MULTISTRATO “AL-COBRAPEX”
13A PRESS-FITTINGS FOR MULTILAYER PIPE “AL-COBRAPEX”
1664CG 1664CG55
Staffa e raccordi 105° terminali Staffa e raccordi 105° terminali
COBRAFIX per pareti in COBRAFIX per pareti in
cartongesso sp. 13 mm cartongesso sp. 13 mm
105° End fittings with bracket 105° End fittings with bracket
COBRAFIX for plasterboard walls COBRAFIX for plasterboard walls
sp.13 mm sp.13 mm
BREVETTATO/PATENTED BREVETTATO/PATENTED
Interasse/ distance between centres: 150 mm Interasse/ distance between centres: 55 mm
Codice Tipo Prezzo € Conf. Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box Code Size Price € Unit/Box
165 1060 16 x 1/2" 1/5 165 1236 16 x 1/2" 1/5
165 1271 20 x 1/2” 1/5 165 1272 20 x 1/2” 1/5
1664CGXL 1664CG55XL
Staffa e raccordi 105° terminali Staffa e raccordi 105° terminali
COBRAFIX per pareti in COBRAFIX per pareti in
cartongesso sp. 20 mm cartongesso sp. 20 mm
105° End fittings with bracket 105° End fittings with bracket
COBRAFIX for plasterboard walls COBRAFIX for plasterboard walls
sp.20 mm sp.20 mm
BREVETTATO/PATENTED BREVETTATO/PATENTED
Interasse/ distance between centres: 150 mm Interasse/ distance between centres: 55 mm
Codice Tipo Prezzo € Conf. Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box Code Size Price € Unit/Box
165 1311 16 x 1/2" 1/5 165 1312 16 x 1/2" 1/5
165 1313 20 x 1/2” 1/5 165 1314 20 x 1/2” 1/5
1664CG SEZIONE/ INTERASSE 1664CG55 SEZIONE/ INTERASSE
1664CGXL SECTION/ DISTANCE BETWEEN CENTRES 1664CG55XL SECTION/ DISTANCE BETWEEN CENTRES
1664CG 1664CGXL 1664CG55 1664CG55XL
Max. 13 Max. 20 Max. 13 Max. 20
50 50 50 50
229
10
10
