Elementi di collegamento aquatherm blue pipe

Rubinetto di scarico maschio/femmina Materiale: fusiolen® PP-R / ottone
SDR 6 / 7,4 / 9 / 11 - per valvole aquatherm green pipe Colore: verde

Articolo no. d l D z z1 h kg Conf. GP Prezzo [€]
Saldatura a tasca
1050020183 20 26,0 34,0 11,5 16,5 71,0 0,098 1 A 13,78
1050025184 25 26,0 34,0 10,0 16,5 71,0 0,096 1 A 13,78
1050032185 32 32,0 43,0 14,0 17,0 74,5 0,118 1 A 14,52
1050040186 40 32,5 52,0 12,0 16,5 80,5 0,140 1 A 14,52
1050050187 50 39,0 68,0 15,5 17,0 88,0 0,202 1 A 19,15
1050063188 63 44,0 84,0 16,5 16,5 96,0 0,288 1 A 21,31

L
Gomito filettato con staffa posteriore Materiale: fusiolen® PP-R / ottone o acciaio inox z 1 l1 z 2
Standard:
DIN 1692, DIN EN ISO 15874
SDR 6 / 7,4 / 11 - ottone o *acciaio inox Colore: verde
c
Articolo no. d R l l1 D D1 L z z1 z2 c kg Conf. GP Prezzo [€] R D1
Saldatura a tasca da un lato z
l
1040020151 20 1/2“ 31,0 31,5 29,5 37,0 51,0 16,5 18,5 13,0 20,0 0,079 10 A 6,99
1040020152 20 3/4“ 37,0 37,0 34,0 44,0 54,0 22,5 24,0 13,0 - 0,106 10 A 11,00 d
D
1040025153 25 3/4“ 37,0 37,0 34,0 44,0 54,0 21,0 24,0 13,0 - 0,105 10 A 11,00
1040025154 25 1/2“ 33,5 31,0 34,0 37,0 53,0 17,5 18,0 13,0 20,0 0,080 10 A 7,19

1090020070 * 20 1/2“ 31,0 31,5 29,5 37,0 51,0 16,5 18,5 13,0 20,0 0,084 1 A 27,72
1090020071 * 20 3/4“ 37,0 37,0 34,0 44,0 54,0 22,5 24,0 13,0 - 0,101 1 A 37,24
1090025072 * 25 3/4“ 37,0 37,0 34,0 44,0 54,0 21,0 24,0 13,0 - 0,111 1 A 37,24
1090025073 * 25 1/2“ 33,5 31,0 34,0 37,0 53,0 17,5 18,0 13,0 20,0 0,076 1 A 27,72
*acciaio inox l1
z 1
Gomito filettato femmina con staffa intermedia Materiale: fusiolen® PP-R / ottone o acciaio inox z R D1
SDR 6 / 7,4 / 11 - ottone o *acciaio inox Standard: DIN 16962, DIN EN ISO 15874 l
verde
Colore:
d
D
Articolo no. d l l1 D D1 z z1 R kg Conf. GP Prezzo [€] c
Saldatura a tasca da un lato
1040020156 20 30,0 37,0 29,5 37,0 15,5 24,0 1/2“ 0,079 10 A 9,87

1090020074 * 20 30,0 37,0 29,5 37,0 15,5 24,0 1/2“ 0,078 1 A 32,85
*acciaio inox

Gomito filettato maschio con controdado Materiale: fusiolen® PP-R / ottone
Standard: DIN 16962, DIN EN ISO 15874
SDR 6 / 7,4 / 11 - con guarnizione e rondella Colore: verde
l2 l1
Articolo no. d l l1 l2 D D1 L z R SW kg Conf. GP Prezzo [€]
Saldatura a tasca da un lato
D1
R
1050020062 20 37,0 3,5 35,0 29,5 44,0 35,0 22,5 1/2“ 29 0,154 10 A 19,28 z
l
1050025063 25 37,0 3,5 37,0 34,0 44,0 37,0 21,0 1/2“ 29 0,206 10 A 19,28 SW
d
D

Pagina 101
