aquatherm green pipe TI aquatherm green pipe

aquatherm green pipe TI SDR 9 MF RP con isolamento in schiuma rigida PUR l
e rivestimento in PE z
Gomito 90° SL 500
Articolo no. Ø tubo interno d Ø tubo esterno D z l kg Conf. GP Prezzo [€] d D
Saldatura a tasca
1383032040 32 90,0 225,0 500 1,120 1 C 153,43
1383040041 40 110,0 225,0 500 1.433,681 1 C 186,64
1383050042 50 110,0 225,0 500 1,812 1 C 197,46
1383063043 63 125,0 225,0 500 2,513 1 C 217,38
1383075044 75 140,0 225,0 500 3,294 1 C 284,99
Disponibile anche nella versione da 60° e 75°.

aquatherm green pipe TI SDR 9 MF RP con isolamento in schiuma rigida PUR l
e rivestimento in PE z
Gomito 90° SL 1000
Articolo no. Ø tubo interno d Ø tubo esterno D z l kg Conf. GP Prezzo [€] d D
Saldatura a tasca
1383032020 32 90,0 225,0 1000 2,582 1 C 190,65
1383040021 40 110,0 225,0 1000 3,770 1 C 233,95
1383050022 50 110,0 225,0 1000 4,293 1 C 248,85
1383063023 63 125,0 225,0 1000 6,000 1 C 284,88
1383075024 75 140,0 225,0 1000 7,341 1 C 369,84
1383090025 90 160,0 225,0 1000 8,988 1 C 445,83
1383110026 110 200,0 225,0 1000 14,523 1 C 575,53
1383125027 125 225,0 225,0 1000 18,239 1 C 763,95
Saldatura di testa
1383160028 160 250,0 225,0 1000 24,112 1 C 880,16
Disponibile anche nella versione da 60° e 75°.

aquatherm green pipe TI SDR 9 MF RP con isolamento in schiuma rigida
PUR e rivestimento in PE
T SL 500
Articolo no. Ø tubo interno d Ø tubo esterno D z l kg Conf. GP Prezzo [€] l
Saldatura a tasca
1363032001 32 90,0 225,0 500 1,633 1 C 154,81 d D
1363040002 40 110,0 225,0 500 2,243 1 C 187,49 z
L
1363050003 50 110,0 225,0 500 2,500 1 C 197,86
1363063004 63 125,0 225,0 500 3,500 1 C 225,78
1363075005 75 140,0 225,0 500 4,712 1 C 282,40
1363090006 90 160,0 225,0 500 6,440 1 C 319,65
1363110007 110 200,0 225,0 500 9,323 1 C 424,34
1363125008 125 225,0 225,0 500 0,012 1 C 525,27
Saldatura di testa
1363160009 160 250,0 225,0 500 0,016 1 C 637,98

aquatherm green pipe ti SDR 9 da 200 mm in poi sono disponibili su richiesta.

Pagina 49
