Page 114 - VALSIR - LISTINO ITS 2024 - FIDRA

GAMMA SILERE

SISTEMI
SISTEMI
SCARICO
SCARICO
HTB curva 45° L 2
Z 2
45°
Z 1
L 1
D/DN

COD. D DN Z 1 L 1 Z 2 L 2 kg CL €/pz
VS0221005 58 50 28 70 17 55 0,257 4 SL02 12,91
VS0221015 78 70 37 60 21 60 0,293 4 SL02 13,50
VS0221025 90 90 22 60 20 60 0,331 4 SL02 17,22
VS0221035 110 100 44 61 28 65 0,585 4 SL02 18,69
VS0221045 135 125 50 64 34 70 0,832 4 SL02 27,83
VS0221055 160 150 30 66 42 70 1,170 4 SL02 37,32

HTB curva 67°30’ L
2 Z
2
67°30’

Z 1
L 1

D/DN

COD. D DN Z L Z L kg CL €/pz
1 1 2 2
VS0221007 58 50 32 70 21 55 0,201 4 SL02 12,15
VS0221017 78 70 26 60 26 60 0,293 4 SL02 12,73
VS0221037 110 100 44 61 44 65 0,619 4 SL02 17,57

HTB curva 87°30’ L 2 Z 2
87°30’

Z 1
L 1
D/DN

COD. D DN Z L Z L kg CL €/pz
1 1 2 2
VS0221009 58 50 47 70 32 55 0,224 4 SL02 13,85
VS0221019 78 70 62 60 42 60 0,319 4 SL02 13,85
VS0221029 90 80 49 60 42 60 0,380 4 SL02 18,34
VS0221039 110 100 78 61 58 65 0,722 4 SL02 19,63
VS0221049 135 125 96 64 102 70 1,084 4 SL02 31,67
VS0221059 160 150 83 66 89 70 1,427 4 SL02 44,64

112
