Page 178 - OLI - OLIFLEX
P. 178
Passaggio a tetto per spessori max D
400 mm. 4
D
Passage to the roof for thicknesses 3
up to 400 mm.
L 1
STOP
agli incendi
the fires
H solaio/tetto
Cod. D D D D L
int est 3 4 H attic/roof 1
OL0162681 80 130 150 350 400 1000 1
OL0162682 100 150 170 370 400 1000 1
OL0162683 130 200 200 400 400 1000 1
OL0162684 150 200 220 420 400 1000 1
OL0162685 180 230 250 450 400 1000 1
OL0162686 200 250 370 470 400 1000 1
Fascia di ancoraggio. 50
Anchor band.
26
140 140
43 19 44
14
100 32 D 8 50 100
Plus 400
Fire protection
Cod. D D D
int est
OL0162761 80 130 348 1
OL0162762 100 150 368 1
OL0162763 130 200 498 1
OL0162764 150 200 418 1
OL0162765 180 230 448 1
OL0162766 200 250 468 1
Da abbinare al passaggio a tetto, necessario per l’ancoraggio alla soletta, la regolazione di eventuale pendenza e per il sostegno del peso.
To be combined with the passage to the roof, necessary for anchoring to the slab, adjusting any slope and for supporting the weight.
