GOOD'SLEEP FILTRO HD

LE UNITÀ INTERNE

MODELLO AM015KNQDEH/EU AM022KNQDEH/EU AM028KNQDEH/EU AM036KNQDEH/EU AM045KNQDEH/EU AM056KNQDEH/EU AM071KNQDEH/EU AM093MNQDEH/EU
Alimentazione Ф, #, V, Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Modalità - HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR
5.60
3.6
Capacità Capacità Raffrescamento kW 1.50 2.20 2.80 4.00 4.50 6.30 6.80 9.30
nominale
9.80
5.00
7.00
Riscaldamento
kW
1.70
3.20
2.50
Potenza assorbita Raffrescamento W 32.00 32.00 38.00 42.00 47.00 48.00 51.00 66.00
nominale Riscaldamento 34.00 35.00 39.00 42.00 47.00 48.00 53.00 76.00
Assorbimento
Corrente assorbita Raffrescamento 0.20 0.20 0.22 0.23 0.27 0.27 0.28 0.47
nominale Riscaldamento A 0.20 0.20 0.22 0.23 0.27 0.27 0.28 0.54
Tipo - Crossflow Fan Crossflow Fan Crossflow Fan Crossflow Fan Crossflow Fan Crossflow Fan Crossflow Fan Crossflow Fan
Motore
Output W 19 x 1 19 x 1 19 x 1 19 x 1 28 x 1 28 x 1 28 x 1 58 x 1
3
m /min 6.20/5.70/5.10 6.60/5.70/5.10 7.00/6.20/5.50 8.50/7.50/6.60 13.90/12.40/11.20 14.40/12.90/11.20 15.70/14.10/12.90 23.00/20.00/17.00
Ventilatore Portata aria Alta / Media / Bassa
l/s 103.30/95.00/85.00 110.00/95.00/85.00 116.70/103.30/91.70 141.70/125.00/110.00 231.70/206.70/186.70 240.00/215.00/186.70 261.70/235.00/215.00 383.00/333.00/283.00
mmH 2 O - - - - - - - -
Pressione statica esterna Min. / Std. / Max.
Pa - - - - - - - -
Ф, mm 6.35 6.35 6.35 6.35 6.35 6.35 9.52 9.52
Tubazione liquido
Ф, inch 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 3/8" 3/8"
Tubazioni
frigorifere Tubazione gas Ф, mm 12.70 12.70 12.70 12.70 12.70 12.70 15.80 15.80
Ф, inch 1/2" 1/2" 1/2" 1/2" 1/2" 1/2" 5/8" 5/8"
Scarico condensa Ф, mm ID 18 HOSE ID 18 HOSE ID 18 HOSE ID 18 HOSE ID 18 HOSE ID 18 HOSE ID 18 HOSE ID 18 HOSE
Cavi Cavo alimentazione < 20m mm 2 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
collegamento Cavo comunicazione mm 2 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75
Tipo - R410A R410A R410A R410A R410A R410A R410A R410A
Refrigerante
Controllo - EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa
Pressione sonora Alta / Media / Bassa dB(A) 30 / 28 / 25 31 / 28 / 25 31 / 29 / 26 36 / 33 / 29 38 / 35 / 33 39 / 36 / 33 40 / 38 / 35 49 / 46 / 42
Rumorosità
Potenza sonora Raffrescamento dB(A) 47 48 48 51 53 53 55 66
Peso netto kg 8.5 8.5 9.0 9.0 12.5 12.5 12.5 18.5
Dimensionali
Dimensioni nette (LxAxP) mm 820 x 285 x 227 820 x 285 x 227 820 x 285 x 227 820 x 285 x 227 1065 x 298 x 243 1065 x 298 x 243 1065 x 298 x 243 1280 x 345 x 253
Accessori Pompa sollevamento condensa Pompa - - - - - - - - -
standard (opzionale) Prevalenza mmH 2 O - - - - - - - -
inclusi
Filtro aria - incluso incluso incluso incluso incluso incluso incluso incluso
