FILTRO FILTRO POMPA SCARICO
INCLUSO REMOVIBILE CONDENSA
LE UNITÀ INTERNE
MODELLO AM022ANMPKH/EU AM028ANMPKH/EU AM036ANMPKH/EU AM045ANMPKH/EU AM056ANMPKH/EU AM071ANMPKH/EU AM090ANMPKH/EU
Alimentazione Ф, #, V, Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Modalità - HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR
Capacità Capacità Raffrescamento kW 2.20 2.80 3.60 4.50 5.60 7.10 9.00
nominale Riscaldamento kW 2.50 3.20 4.00 5.00 6.30 8.00 10.00
Potenza assorbita Raffrescamento W 42.00 42.00 45.00 55.00 70.00 110.00 135.00
nominale Riscaldamento 42.00 42.00 45.00 55.00 70.00 110.00 135.00
Assorbimento
Corrente assorbita Raffrescamento 0.40 0.40 0.40 0.50 0.60 1.00 1.20
nominale Riscaldamento A 0.40 0.40 0.40 0.50 0.60 1.00 1.20
Tipo - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motore
Output W 153 x 1 153 x 1 153 x 1 153 x 1 153 x 1 153 x 1 153 x 1
3
m /min 10.50 / 9.00 / 7.00 10.50 / 9.00 / 7.00 12.00 / 9.50 / 7.50 14.00 / 11.00 / 8.00 16.00 / 13.50 / 9.00 21.00 / 18.00 / 13.00 27.00 / 22.00 / 16.00
Ventilatore Portata aria Alta / Media / Bassa
l/s 175.00 / 150.00 / 117.00 175.00 / 150.00 / 117.00 208.00 / 158.33 / 133.33 233.33 / 183.33 / 133.33 266.67 / 225.00 / 150.00 350.00 / 300.00 / 217.00 450.00 / 367.00 / 267.00
mmH 2 O 0.00 / 2.50 / 15.00 0.00 / 2.50 / 15.00 0.00 / 2.50 / 15.00 0.00 / 3.00 / 15.00 0.00 / 3.00 / 15.00 0.00 / 3.00 / 15.00 0.00 / 4.00 / 15.00
Pressione statica esterna Min. / Std. / Max.
Pa 0.00 / 24.52 / 147.10 0.00 / 24.52 / 147.10 0.00 / 24.52 / 147.10 0.00 / 29.40 / 147.00 0.00 / 29.40 / 147.00 0.00 / 29.40 / 147.00 0.00/ 39.20 / 147.00
Ф, mm 6.35 6.35 6.35 6.35 6.35 9.52 9.52
Tubazione liquido
Ф, inch 1/4" 1/4" 1/4" 1/4" 1/4" 3/8" 3/8"
Tubazioni Ф, mm 12.70 12.70 12.70 12.70 12.70 15.88 15.88
frigorifere Tubazione gas
Ф, inch 1/2" 1/2" 1/2" 1/2" 1/2" 5/8" 5/8"
Scarico condensa Ф, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Cavi Cavo alimentazione < 20m mm 2 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
collegamento Cavo comunicazione mm 2 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Tipo - R410A R410A R410A R410A R410A R410A R410A
Refrigerante
Controllo - EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa
Pressione sonora Alta / Media / Bassa dB(A) 28 / 26 / 24 28 / 26 / 24 30 / 27 / 24 31 / 28 / 25 32 / 29 / 25 36 / 32 / 27 37 / 33 / 29
Rumorosità
Potenza sonora Alta / Media / Bassa dB(A) 50 51 53 54 57 60 61
Peso netto kg 27.90 27.90 27.50 27.50 27.50 27.50 35.00
Dimensionali
Dimensioni nette (LxAxP) mm 850 x 250 x 700 850 x 250 x 700 850 x 250 x 700 850 x 250 x 700 850 x 250 x 700 850 x 250 x 700 1200 x 250 x 700
Pompa interna inclusa inclusa inclusa inclusa inclusa inclusa inclusa
Accessori Pompa sollevamento condensa
standard Prevalenza mmH 2 O 750 750 750 750 750 750 750
inclusi
Filtro aria - Incluso Incluso Incluso Incluso Incluso incluso incluso
