Attrezzature vuoto e/o carico Vacuum and charge equipments
MANIFOLD CON SONDE MANIFOLD CON SONDE
Manifold with probes Manifold with probes
Temperatura di stoccaggio / Storage temperature -20°C/+60°C (-4F/140F)
TEMPERATURA / TEMPERATURE
Numero di sonde / Probe number 2 sonde a pinza / 2 probes with pliers
Termistori NTC ad alta precisione / NTC high precision ther-
Sonde di temperatura / Temperature probes
mistors
Campo sensore temperatura / Temperature sensor field -40°C/+150°C (-40F/302F)
Precisione temperatura / Temperature accuracy +1 1.3°C / +33,8 34,34 F
Pinze: 150°C / Cavo: 105°C / Maniglie: 90°C
Temperature max di funzionamento / Max operating temperature
Pliers: 150°C (302F) Cable: 105°C (221F) Handles: 90°C (194F)
Unità disponibili / Available units °C, F, K
Risoluzione / Risolution 0.1°C, 0.1 F, 0.1 K
Diametri tubazioni / Pipe diameters da 6 a 42 mm / from 0,23” to 1,65”
SI-RM3 1 pz 966,50 2 m di lunghezza con connettore jack rinforzato
3 punti, diam. 3,2 mm, in PVC, temperatura max 105°C /
Cavo / Cable
78,74” long with reinforced jack connector
Si-RM3 di Sauermann offre agli installatori uno Si-RM3 by Sauermann offers installers an ergonomic tool 3 points, diam. 0,12”, made of PVC, max temperature 221F
strumento ergonomico adatto a luoghi stretti e angusti, suitable for narrow and cramped places, an Si-Manifold
una App Si-Manifold con Bluetooth® fino a 30 metri e la App with Bluetooth® up to 30 meters (198,42 ft) and the Temperatura di funzionamento / Operating temperature -20°C/+50°C (-4F/122F)
capacità di eseguire una serie di letture importanti in ability to perform a series of important readings in an
dispositivo tutto-in-uno. all-in-one device.
Temperatura di stoccaggio / Storage temperature -20°C/+60°C (-4F/140F)
CARATTERISTICHE PRINCIPALI: MAIN FEATURE:
•leggero ed ergonomico per una facile connessione •lightweight and ergonomic for easy connection to the CONDIZIONI AMBIENTALI DI UTILIZZO /
all’impianto; plant; Using environmental conditions
•sistema a doppia valvola; •double valve system; non in condizioni di condensazione (<80% UR)/
•valvola con attacco tipo Schrader; •valve with Schrader type connection; Umidità / Umidity not in condensing conditions (<80% UR)
•campo fino a 60 bar; •range up to 60 bar;
•riduce l’uso di tubi ingombranti; •reduces the use of bulky pipes;
•due sonde a pinza di temperatura; •two temperature clamp probes; Gas / Gases non corrosivi o infiammabili / not corrosive and flammable
•bluetooth 4.2 a basso consumo con portata fino a 30m. •low power Bluetooth 4.2 with range up to 30m (198,42 ft).
Massima altitudine / Maximum altitude 2000m / 6561,68 ft
VACUOMETRO / VACUUM GAUGE Durata batteria / Battery life 250h
Classe 1 bluetooth 4.2 fino a 30m /
Valvole di pressione / Pressure valves 2 vie / 2 ways Bluetooth / Bluetooth
Bluetooth class 1 4.2 until 30 m (98,42 ft)
Campo di misura / Measuring range da -1 a 60 bar / from -1 to 60 bar Surriscaldamento e sottoraffreddamento / Calcolati automaticamente dall’applicazione /
Overheating and undercooling Automatically calculated by the application
Precisione rilevamento pressione / +-0,5% dell’intera scala / +-0,5% of the entire range 126 gas refrigeranti. Prodotti misurabili:
Pressure detection accuracy CFC,HFC,HCFC,N,CO2,H2O.
Database refrigeranti / Refrigerants database
Unità disponibili / Available units psi,MPa,kPa,bar,Foot of head 126 refrigerant gases. Measurable products:
CFC,HFC,HCFC,N,CO2,H2O.
Risoluzione / Resolution 0.1 psi, 0.001MPa, 1 kPa, 0.01 bar, 1 foot of head CONNESSIONI / CONNECTIONS
Sovrapressione / Overpressure 65 bar / 942,74 psi F1/4” FFL con depressore Schrader / with Schrader depres-
Lato installazione / Installation side
sor
Pressione di rottura / Breaking pressure 150 bar / 2175,57 psi
Lato flessibile / Flexible side M1/4” MFL con valvola tipo Schrader / with Schrader valve
Temperatura di funzionamento / 2011/65/EU RoHS II; 2012/19/EU WEEE; 2014/30*/EU EMC;
Operating temperature -20°C/+50°C (-4F/122F) Standard e direttive / Standard and Directives
2014/53/EU RED.
Prezzo al pezzo / Price per piece.
