P. 167
Bathroom / Sly
Specifiche / specifications Accessori / accessories
SY 010CR SY 015CR SY 018-019CR PBOX 001 SY BOX010CR SY BOX015CR
Miscelatore incasso doccia Miscelatore incasso doccia con deviatore Miscelatore incasso doccia con deviatore Set incasso universale per miscelatori doccia Set esterno miscelatore incasso Set esterno miscelatore incasso
Concealed shower mixer Concealed shower mixer with diverter 2 uscite/3 uscite Universal Concealed Box for mixers doccia senza deviatore doccia con deviatore
Concealed shower mixer with diverter External set for concealed External set for concealed shower
2 outlets/3 outlets shower mixer without diverter mixer with diverter
Ø200 ∅200
∅116 11 137 max. 90
G1/2" 112 min. 65 Ø173 Ø173
G 1/2"
1/2"G 68 68 60
min.
30 G 1/2" ∅48
max. 147 120 119 131 ∅48
50 G 1/2"
8 8 13 13
G 1/2"
* * *
Da abbinare solo con Da abbinare solo con Da abbinare solo con
SY BOX010 - SY BOX015 PBOX 001 PBOX 001
To be completed only with To be completed only with To be completed only with
SY BOX010 - SY BOX015 PBOX 001 PBOX 001
SY 022-023CR SY 168-168DCR SY 071-075CR SY 131-135CR Finiture / finishes
Miscelatore vasca/doccia con/ Miscelatore doccia con/senza set Miscelatore lavabo con/senza Miscelatore bidet con/senza
senza set doccia doccia scarico scarico
Bath/shower mixer with/without Wall mounted shower mixer with/ Wash basin mixer with/without pop Bidet mixer with/without pop up
shower set without shower set up waste waste
SY 071-075CR-ES
76 G1/2" Con cartuccia ENERGY SAVING
G1/2" G1/2" 92 With ENERGY SAVING cartridge
G1/2" 50
60 48
148 55 76 115 122
CR
Cromo
141
141
Chrome plated
∅64
150±20 20 ∅64 150±20 20 55x55 88 55x55 91
166 167
