P. 354
18 ACCESSORI E RICAMBI PER COLLETTORI
ACCESSORIES AND SPARE PARTS FOR MANIFOLDS
Valvole a sfera passaggio totale
Full bore ball valves
2180CPR 2120R
Valvola a squadra con pretenuta Valvola diritta con attacco
e GUARNIZIONE PIANA termometro reversibile
Angle valve and FLAT WASHER Straight valve with thermometer
reversible connection
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box BREVETTATO/PATENTED
leva rossa/ red handle Codice Tipo Prezzo € Conf.
212 0056 3/4” 10/40 Code Size Price € Unit/Box
212 0057 1” 5/20 leva rossa/ red handle
212 0043 1” 5/20
leva blu/ blue handle
212 0054 3/4” 10/40 leva blu/ blue handle
212 0042 1” 5/20
212 0045 1” 5/20
2181CPR 2183R
Valvola a squadra ISO 228 con
Valvola a squadra con pretenuta pretenuta, tenuta con O-RING
e GUARNIZIONE PIANA e termometro con attacco
Angle valve with FLAT WASHER reversibile
Angle valve ISO 228 with O-RING
and thermometer with reversible
connection
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box
leva rossa/ red handle BREVETTATO/PATENTED
162 0045 20 x 3/4” 10/40
Codice Tipo Prezzo € Conf.
162 0014 26 x 3/4” 10/40 Code Size Price € Unit/Box
162 0010 26 x 1” 5/20 leva rossa/ red handle
162 0015 32 x 1” 5/20 212 0031 1” 5/20
leva blu/ blue handle leva blu/ blue handle
162 0046 20 x 3/4” 10/40 212 0032 1” 5/20
162 0004 26 x 3/4” 10/40
162 0009 26 x 1” 5/20
162 0013 32 x 1” 5/20
Per gamma completa valvole a sfera vedi capitolo 1 A
For all ball valves see chapter 1A
334 For pricelist scan the QR code
