18 COLLETTORI DI DISTRIBUZIONE DA BARRA
BRASS BAR DISTRIBUTION MANIFOLDS
Utilizzabili con cassetta 1810, 1812, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1920-1930 and 1939-1940 (pag. 342)
3039 3042
Collettore di distribuzione in Collettore di distribuzione in
ottone CW617N completo ottone CW617N completo di
di valvole di intercettazione vitoni a memoria meccanica
manuale termostatizzabili Manifold made by CW617N
Manifold made by CW617N brass with mechanical balancing
brass with manually valves with screws
option for thermal actuators 3/4”
18
3/4”
18
Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
Codice Mandata N. vie Uscite Prezzo € Conf. 303 0028 1"G 2 3/4”(ø18) 1/10
Code Delivery Ways Outlets Price € Unit/Box
303 0024 1"G 2 3/4”(ø18) 1/10 303 0019 1"G 3 3/4”(ø18) 1/10
303 0014 1"G 3 3/4”(ø18) 1/10 303 0049 1"G 4 3/4”(ø18) 1/6
303 0027 1"G 4 3/4”(ø18) 1/6 303 0050 1"G 5 3/4”(ø18) 1/6
303 0012 1"G 5 3/4”(ø18) 1/6 303 0025 1"G 6 3/4”(ø18) 1/6
303 0015 1"G 6 3/4”(ø18) 1/6 303 0023 1"G 7 3/4”(ø18) 1/6
303 0029 1"G 7 3/4”(ø18) 1/6 303 0051 1"G 8 3/4”(ø18) 1/6
303 0009 1"G 8 3/4”(ø18) 1/6 303 0052 1"G 9 3/4”(ø18) 1/5
303 0030 1"G 9 3/4”(ø18) 1/5 303 0053 1"G 10 3/4”(ø18) 1/5
303 0011 1"G 10 3/4”(ø18) 1/5 303 0054 1"G 11 3/4”(ø18) 1/5
303 0031 1"G 11 3/4”(ø18) 1/5 303 0055 1"G 12 3/4”(ø18) 1/3
303 0032 1"G 12 3/4”(ø18) 1/3
3039-3040 GUIDA ALLE CONNESSIONI
3040 3042 CONNECTION GUIDE
Collettore di distribuzione in
ottone CW617N completo di
flussimetri per la misurazione e
regolazione della portata
Manifold made by CW617N
brass with manually valves with
balancing flow meters for circuit
calibration
3/4”
18
Codice Mandata N. vie Uscite Prezzo € Conf. 1241 144 0104
Code Delivery Ways Outlets Price € Unit/Box 144 0071
303 0003 1"G 2 3/4”(ø18) 1/10 1636 1666 1436 1716 Per tubo rame
303 0002 1"G 3 3/4”(ø18) 1/10 For copper pipe Tappo
Cap
303 0001 1"G 4 3/4”(ø18) 1/6 Per tubo multistrato Per tubo Pe-x Adattatore per sede piana
For multilayer pipe For Pe-x pipe Flat seat adaptor
303 0004 1"G 5 3/4”(ø18) 1/6
303 0005 1"G 6 3/4”(ø18) 1/6
303 0007 1"G 7 3/4”(ø18) 1/6
303 0006 1"G 8 3/4”(ø18) 1/6
303 0039 1"G 9 3/4”(ø18) 1/5
303 0016 1"G 10 3/4”(ø18) 1/5
303 0040 1"G 11 3/4”(ø18) 1/5
303 0041 1"G 12 3/4”(ø18) 1/3
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
