DATI PRESTAZIONALI
DATI TECNICI EUROVENT EN 14511:2013
HMI040 HMI060 HMI080 HMI100 HMI100T HMI120 HMI120T HMI140 HMI140T HMI160 HMI160T
Prestazioni in raffreddamento 12 °C / 7 °C - EN 14511:2013 (1)
Potenza frigorifera kW 3,00 4,00 5,00 7,80 7,80 9,50 9,50 12,00 12,00 13,00 13,00

Potenza assorbita kW 0,94 1,29 1,61 2,48 2,64 3,20 3,11 4,14 4,38 4,96 4,91
Corrente assorbita A 4,3 5,9 7,7 11,4 4,0 14,7 4,7 19,0 6,7 22,7 7,5
EER W/W 3,19 3,10 3,11 3,15 2,95 2,97 3,05 2,90 2,74 2,62 2,65
Portata acqua l/h 516 672 860 1320 1270 1650 1665 2080 2065 2270 2231
Prevalenza utile kPa 75,0 74,0 74,0 71,0 71,0 65,0 64,0 51,0 51,0 45,0 46,0
Prestazioni in riscaldamento 40 °C / 45 °C - EN 14511:2013 (2)
Potenza termica kW 4,00 6,00 7,50 10,00 10,00 12,00 12,00 14,00 14,00 15,50 15,50

Potenza assorbita kW 1,00 1,58 2,00 2,70 2,70 3,48 3,48 4,18 4,18 4,70 4,70
Corrente assorbita A 4,6 7,2 9,2 12,4 4,1 15,9 5,3 19,1 6,4 21,5 7,1
COP W/W 4,00 3,80 3,75 3,70 3,70 3,45 3,45 3,35 3,35 3,30 3,30
Portata acqua l/h 690 977 1240 1700 1710 2050 2040 2500 2474 2700 2734
Prevalenza utile kPa 74,0 73,0 72,0 63,0 63,0 52,0 52,0 37,0 38,0 30,0 29,0
(1) Dati EN 14511:2013; Acqua scambiatore lato utenza 12 °C / 7 °C; Aria esterna 35 °C
ARIA-ACQUA (2) Dati EN 14511:2013; Acqua scambiatore lato utenza 40 °C / 45 °C; Aria esterna 7 °C b.s. / 6 °C b.u. HMI080 HMI100 HMI100T HMI120 HMI120T HMI140 HMI140T HMI160 HMI160T ARIA-ACQUA
HMI060
HMI040
Prestazioni in raffreddamento 23 °C / 18 °C - EN 14511:2013 (1)
Potenza frigorifera kW 3,80 5,80 6,80 8,80 8,80 11,00 11,00 12,50 12,50 14,50 14,50
Potenza assorbita kW 0,82 1,32 1,55 1,96 1,96 2,56 2,56 3,05 3,05 3,82 3,82
Corrente assorbita A 3,8 6,0 7,1 9,0 3,0 11,7 3,9 14,0 4,6 17,5 5,8
EER W/W 4,63 4,39 4,39 4,49 4,49 4,30 4,30 4,10 4,10 3,80 3,80
Portata acqua l/h 660 981 1220 1510 1500 1926 1900 2238 2200 2640 2570
Prevalenza utile kPa 74,0 73,0 72,0 69,0 69,0 56,0 57,0 46,0 47,0 32,0 34,0
Prestazioni in riscaldamento 30 °C / 35 °C - EN 14511:2013 (2)

Potenza termica kW 4,00 6,00 7,50 10,00 10,00 12,00 12,00 14,00 14,00 15,50 15,50
Potenza assorbita kW 0,79 1,20 1,63 2,17 2,17 2,64 2,64 3,22 3,22 3,60 3,60
Corrente assorbita A 3,6 5,5 7,5 9,9 3,3 12,1 4,0 14,7 4,9 16,5 5,5
COP W/W 5,10 5,00 4,60 4,61 4,61 4,55 4,55 4,35 4,35 4,31 4,31
Portata acqua l/h 690 1030 1247 1736 1720 2137 2100 2524 2400 2703 2626
Prevalenza utile kPa 74,0 73,0 72,0 62,0 62,0 49,0 50,0 36,0 40,0 30,0 32,0

(1) Dati EN 14511:2013; Acqua scambiatore lato utenza 23 °C / 18 °C; Aria esterna 35 °C
(2) Dati EN 14511:2013; Acqua scambiatore lato utenza 30 °C / 35 °C; Aria esterna 7 °C b.s. / 6 °C b.u.
DATI TECNICI EUROVENT EN 14511:2018
HMI040 HMI060 HMI080 HMI100 HMI100T HMI120 HMI120T HMI140 HMI140T HMI160 HMI160T
Prestazioni in raffreddamento 12 °C / 7 °C (1)
Potenza frigorifera kW 2,98 3,97 4,96 7,75 7,75 9,45 9,45 11,94 11,94 12,95 12,95
Potenza assorbita kW 0,94 1,29 1,61 2,48 2,64 3,20 3,11 4,14 4,38 4,96 4,91
Corrente assorbita A 4,7 6,4 7,9 12,0 4,6 15,0 5,3 20,0 7,3 23,0 8,1

EER W/W 3,17 3,08 3,08 3,12 2,94 2,95 3,04 2,88 2,73 2,61 2,64
Portata acqua l/h 504 673 842 1318 1318 1609 1609 2038 2038 2210 2210
Prevalenza utile kPa 74,0 74,0 74,0 69,0 69,0 64,0 64,0 52,0 52,0 47,0 47,0
Prestazioni in riscaldamento 40 °C / 45 °C (2)
Potenza termica kW 4,03 6,04 7,55 10,06 10,06 12,06 12,06 14,05 14,05 15,54 15,54
Potenza assorbita kW 1,00 1,58 2,00 2,70 2,70 3,48 3,48 4,18 4,18 4,70 4,70
Corrente assorbita A 5,1 7,8 9,7 13,0 4,7 17,0 5,9 20,0 6,9 22,0 7,7
COP W/W 4,03 3,83 3,78 3,72 3,72 3,46 3,46 3,36 3,36 3,31 3,31

Portata acqua l/h 710 1062 1326 1762 1762 2110 2110 2456 2456 2714 2714
Prevalenza utile kPa 74,0 73,0 71,0 60,0 60,0 50,0 50,0 39,0 39,0 29,0 29,0
(1) Dati EN 14511:2022; Acqua scambiatore lato utenza 12 °C / 7 °C; Aria esterna 35 °C
(2) Dati EN 14511:2022; Acqua scambiatore lato utenza 40 °C / 45 °C; Aria esterna 7 °C b.s. / 6 °C b.u.
HMI040 HMI060 HMI080 HMI100 HMI100T HMI120 HMI120T HMI140 HMI140T HMI160 HMI160T
Prestazioni in raffreddamento 23 °C / 18 °C (1)
Potenza frigorifera kW 3,77 5,76 6,75 8,75 8,75 10,94 10,94 12,44 12,44 14,45 14,45
Potenza assorbita kW 0,82 1,32 1,55 1,96 1,96 2,56 2,56 3,05 3,05 3,82 3,82
Corrente assorbita A 4,2 6,6 7,6 9,5 3,6 12,0 4,5 15,0 5,2 18,0 6,4
EER W/W 4,60 4,36 4,36 4,46 4,46 4,27 4,27 4,08 4,08 3,78 3,78
Portata acqua l/h 641 982 1152 1495 1495 1873 1873 2132 2132 2478 2478
Prevalenza utile kPa 74,0 74,0 73,0 66,0 66,0 57,0 57,0 50,0 50,0 38,0 38,0
Prestazioni in riscaldamento 30 °C / 35 °C (2)
Potenza termica kW 4,03 6,04 7,55 10,06 10,06 12,06 12,06 14,05 14,05 15,54 15,54
Potenza assorbita kW 0,79 1,20 1,63 2,17 2,17 2,64 2,64 3,22 3,22 3,60 3,60

Corrente assorbita A 4,1 6,0 8,0 11,0 3,9 13,0 4,6 15,0 5,5 17,0 6,1
COP W/W 5,10 5,04 4,63 4,63 4,63 4,57 4,57 4,36 4,36 4,32 4,32
Portata acqua l/h 708 1058 1321 1756 1756 2102 2102 2447 2447 2704 2704
Prevalenza utile kPa 74,0 73,0 71,0 60,0 60,0 50,0 50,0 39,0 39,0 30,0 30,0
(1) Dati EN 14511:2022; Acqua scambiatore lato utenza 23 °C / 18 °C; Aria esterna 35 °C
(2) Dati EN 14511:2022; Acqua scambiatore lato utenza 30 °C / 35 °C; Aria esterna 7 °C b.s. / 6 °C b.u.

HMI-HP_I_UN50_13 www.aermec.com 345
