DATI PRESTAZIONALI UNITÀ INTERNA
MVA_WL
MVA220WL MVA280WL MVA360WL MVA450WL MVA500WL MVA560WL MVA630WL MVA710WL
Prestazioni in raffrescamento nominali
Potenza frigorifera (1) kW 2,20 2,80 3,60 4,50 5,00 5,60 6,30 7,10

Prestazioni in riscaldamento nominali
Potenza termica (2) kW 2,50 3,20 4,00 5,00 5,60 6,30 7,10 7,50
Dati elettrici
Potenza nominale assorbita (3) W 20 20 25 35 35 50 50 65
Ventilatore
Tangenziale Tangenziale Tangenziale Tangenziale Tangenziale Tangenziale Tangenziale Tangenziale
Tipo tipo
inverter inverter inverter inverter inverter inverter inverter inverter
Portata d’aria
Minima m³/h 300 300 320 500 501 650 650 650
Media m³/h 440 440 460 580 580 850 850 850
Massima m³/h 500 500 630 850 850 1100 1100 1200
Potenza sonora (4)
Minima dB(A) 40,0 41,0 41,0 47,0 47,0 47,0 48,0 47,0
Media dB(A) 43,0 43,0 45,0 50,0 50,0 51,0 51,0 51,0
Massima dB(A) 45,0 45,0 48,0 53,0 53,0 53,0 53,0 54,0

Pressione sonora (5)
Minima dB(A) 30,0 30,0 31,0 37,0 37,0 37,0 37,0 37,0
Media dB(A) 33,0 33,0 35,0 40,0 40,0 41,0 41,0 41,0
Massima dB(A) 35,0 35,0 38,0 43,0 43,0 43,0 43,0 44,0
Tubazioni frigorifere
Diametro attacchi frigoriferi liquido mm (inch) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 9,52 (3/8”) 9,52 (3/8”) 9,52 (3/8”)
Diametro attacchi frigoriferi gas mm (inch) 9,52 (3/8”) 9,52 (3/8”) 12,7 (1/2”) 12,7 (1/2”) 12,7 (1/2”) 15,9 (5/8”) 15,9 (5/8”) 15,9 (5/8”)
Alimentazione

Alimentazione unità interna 220-240V ~ 50Hz 220-240V ~ 50Hz 220-240V ~ 50Hz 220-240V ~ 50Hz 220-240V ~ 50Hz 220-240V ~ 50Hz 220-240V ~ 50Hz 220-240V ~ 50Hz
Unità interna
Diametro scarico condensa mm 20,0 20,0 20,0 20,0 20,0 20,0 20,0 20,0
(1) Raffrescamento (EN 14511 e EN 14825) temperatura aria ambiente 27 °C b.s. / 19 °C b.u.; temperatura aria esterna 35 °C; velocità turbo; lunghezza linee frigorifere 5 m.
(2) Riscaldamento (EN 14511 e EN 14825) temperatura aria ambiente 20 °C b.s.; temperatura aria esterna 7 °C b.s. / 6 °C b.u.; velocità turbo; lunghezza linee frigorifere 5 m.
(3) La potenza nominale assorbita (corrente nominale assorbita), è la massima potenza elettrica assorbita (corrente massima assorbita) dal sistema, in accordo con la normativa EN 60335-1 e EN 60335-2-40.
(4) Potenza sonora calcolata in campo libero in accordo con UNI EN ISO 3744.
(5) Pressione sonora misurata in camera anecoica a 1,5 m di distanza frontale.

MVA_D
MVA221D MVA251D MVA281D MVA321D MVA361D MVA401D MVA451D MVA501D MVA561D
Prestazioni in raffrescamento nominali
Potenza frigorifera (1) kW 2,20 2,50 2,80 3,20 3,60 4,00 4,50 5,00 5,60
Prestazioni in riscaldamento nominali
Potenza termica (2) kW 2,50 2,80 3,20 3,60 4,00 4,50 5,00 5,60 6,30
Dati elettrici

Potenza nominale assorbita (3) W 78 78 78 78 78 78 78 117 117
Ventilatore
Centrifugo Centrifugo Centrifugo Centrifugo Centrifugo Centrifugo Centrifugo Centrifugo Centrifugo
Tipo tipo
inverter inverter inverter inverter inverter inverter inverter inverter inverter
Portata d’aria
Minima m³/h 200 200 200 300 300 400 400 550 550
Media m³/h 350 350 350 400 400 550 550 700 700
Massima m³/h 450 450 450 550 550 750 750 850 850

Pressione statica utile
Nominale Pa 15 15 15 15 15 15 15 15 15
Minima Pa 0 0 0 0 0 0 0 0 0
Massima Pa 30 30 30 30 30 30 30 30 30
Potenza sonora (4)
Minima dB(A) 32,0 32,0 32,0 35,0 35,0 37,0 37,0 39,0 39,0
Media dB(A) 35,0 35,0 35,0 37,0 37,0 39,0 39,0 41,0 41,0
Massima dB(A) 40,0 40,0 40,0 41,0 41,0 43,0 43,0 45,0 45,0

Pressione sonora (5)
Minima dB(A) 22,0 22,0 22,0 25,0 25,0 27,0 27,0 29,0 29,0
Media dB(A) 25,0 25,0 25,0 27,0 27,0 29,0 29,0 31,0 31,0
Massima dB(A) 30,0 30,0 30,0 31,0 31,0 33,0 33,0 35,0 35,0
Tubazioni frigorifere mm (inch) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 6,35 (1/4”) 9,52 (3/8”)
Diametro attacchi frigoriferi liquido
SISTEMI VRF Diametro attacchi frigoriferi gas mm (inch) 9,52 (3/8”) 9,52 (3/8”) 9,52 (3/8”) 12,7 (1/2”) 12,7 (1/2”) 12,7 (1/2”) 12,7 (1/2”) 12,7 (1/2”) 15,9 (5/8”) SISTEMI VRF
Alimentazione
Alimentazione unità interna 220-240V ~ 220-240V ~ 220-240V ~ 220-240V ~ 220-240V ~ 220-240V ~ 220-240V ~ 220-240V ~ 220-240V ~
50Hz 50Hz 50Hz 50Hz 50Hz 50Hz 50Hz 50Hz 50Hz
Unità interna
Diametro scarico condensa mm 25,0 25,0 25,0 25,0 25,0 25,0 25,0 25,0 25,0

MVBM_I_UN50_03 www.aermec.com 931
