SISTEMI SISTEMI SCARICO SCARICO
GAMMA HDPE

Tubo HDPE L 5000 S Di
L 5000 mm, SDR 26
D/DN cm 2
A

COD. D DN Di S A cm 2 PN kg/m ❑ CL €/m
VS0300119 200 200 184,60 7,7 267,50 4 4,827 70 14 PE01 57,43
VS0300121 250 250 230,80 9,6 418,16 4 7,676 55 11 PE01 90,35
VS0300123 315 300 290,80 12,1 663,83 4 12,221 30 6 PE01 134,17

Curva 45° L 1

45° S
K
L 1
K
D/DN

COD. D DN S L K kg HxLxP CL €/pz
1
VS0306001 32 30 3 37 20 0,023 50 400 4000 1130x800x1200 PE02 2,82
VS0306003 40 40 3 45 20 0,032 50 400 2400 1060x800x1200 PE02 2,97
VS0306005 50 50 3 45 20 0,042 40 320 1920 1060x800x1200 PE02 3,13
VS0306006 56 56 3 45 20 0,047 30 240 1440 1060x800x1200 PE02 4,32
VS0306007 63 60 3 50 20 0,060 40 320 1600 1180x800x1200 PE02 4,49
VS0306009 75 70 3 50 20 0,073 25 200 1000 1180x800x1200 PE02 7,11
VS0306011 90 90 3,5 55 20 0,113 20 160 480 1015x800x1200 PE02 11,23
VS0306013 110 100 4,3 60 25 0,177 25 100 400 1050x800x1200 PE02 12,08
VS0306015 125 125 4,8 65 25 0,244 15 60 240 1050x800x1200 PE02 14,88
VS0306017 160 150 6,2 69 20 0,428 1 - 160 930x800x1200 PE02 50,49

Curva 45° a raggio
lungo L
45°

R K
L
K
s
D/DN

COD. D DN S L R K kg HxLxP CL €/pz

VS0306019 200 200 6,2 217 230 125 1,643 1 - 32 930x800x1200 PE02 100,92
VS0306021 250 250 7,8 231 270 125 2,702 1 - 18 930x800x1200 PE02 141,55
VS0306023 315 300 9,8 249 325 125 4,639 1 - 10 930x800x1200 PE02 186,11
A segmenti.

127
