Page 13 - OLI - OLIFLEX
P. 13
Fire protection Plus 400 brevettato e testato secondo
NEW 2023 EN 13216-1, sia con temperature costanti a 700°C sia a
1000°C per 30 minuti, nella con gurazione di tipo “C - non
chiuso” (EN 1443), può essere installato a diretto contatto
con i solai e i tetti in legno o materiale combustibile in
genere, con spessori no a 400 mm.
Fire protection Plus 400 patented and tested according to
the standards of the European standard EN 13216-1, both
with a constant temperature of 700°C and at 1000°C for 30
minutes, in the configuration of type “C - non enclosed”
(EN 1443), it can be installed in direct contact with attics
and roofs made of wood and combustible material with
thicknesses up to 400 mm.
T600 G00 UNI EN 400 mm F1P2C F2P2C PELLET
1000°C 13216-1
WC100 E0
Fire protection certi cato secondo EN 1856-1, sia con
temperature costanti a 700°C sia a 1000°C per 30 minuti,
può essere installato a diretto contatto con i solai e i tetti
in legno o materiale combustibile in genere con spessori
no a 200 mm.
Fire protection certificate according to the standards of
the European standard EN 1856-1, both with a constant
temperature of 700°C and at 1000°C for 30 minutes, it can
be installed in direct contact with attics and roofs made
of wood and combustible material with thicknesses up to
200 mm.
T600 G00 UNI EN 200 mm PELLET RAL
1000°C 1859
OLIflex D.P. Air inox-inox e D.P. Air inox-rame sono
sistemi idonei allo scarico dei prodotti della combustione
di caldaie di tipo “C”, a condensazione, e per generatori
a pellet dove la temperatura dei fumi non supera i 200°C.
OLIflex D.P. Air inox-inox and D.P. Air inox-rame are
chimneys system ideal for the discharge of combustion
products of “C” type condensing boilers and for pellet
generators, where the temperature will be lower than
200°C.
T200 H2 GAS OIL PELLET RAL
5000 Pa
www.oli-world.com 11
