OLI ex PPs
Sistema OLI ex PPs New system OLIflex PPs
Prodotto certi cato CE secondo lo standard EN 14471. CE certified product in compliance with EN 14471.
OLI ex è il sistema in polimero plastico per lo scarico OLIflex is a system in plastic polymer for removal of the
dei prodotti della combustione da generatori a combustion products from condensation boilers.
condensazione. Produced in 50-60-80-100-125-160 mm diameters.
Realizzato nei diametri 50-60-80-100-125-160 mm. This new system, composed of circular modular
Questo nuovo sistema, composto da elementi modulari elements, resists both positive pressure (5,000 Pa) and
a sezione circolare, è adatto al funzionamento sia in negative pressure (40 Pa depression).
pressione positiva (5.000 Pa) sia in pressione negativa The OLIflex system is used principally for both the
(depressione a 40 Pa). discharge of the products of combustion from
Il sistema OLI ex trova le sue principali applicazioni condensation boilers and the removal of cooking
sia nello scarico dei prodotti della combustione da fumes. In the first application the minimum operating
caldaie a condensazione, sia nello scarico dei vapori temperature is T 120°C and the product must
di cottura. Nella prima applicazione la temperatura guarantee a perfect seal against acidic condensation
minima di esercizio è T 120°C ed il prodotto deve that is formed inside the kitchen chimney due to the
garantire una perfetta tenuta alle condense acide, low temperature of the products of combustion. In the
che si formano all’interno della canna fumaria per la second application the minimum required temperature
bassa temperatura dei prodotti della combustione. is T 80° and once more in this case the product must
Nella seconda applicazione la temperatura minima be “W” humidity resistant.
richiesta è T 80° ed anche in questo caso c’è l’obbligo The OLIflex system is composed of rigid and flexible
della resistenza ad umido “W”. elements, in plastic polymer called “PPs”, which are
Il sistema OLI ex è formato da elementi rigidi e essibili, flame-retardant, and that can be combined together.
in polimero plastico denominato “PPs” auto estinguente The system is made up of all the elements that are
che si possono integrare fra loro. required to create a chimney vent, such as: 93° TEE
Compongono il sistema tutti gli elementi che servono fitting, access elements, condensation discharge
alla realizzazione di una canna fumaria: raccordo T 93°, elements, 45° bends, 93° bend with or without access.
elemento d’ispezione, scarico condensa, curve a 45°, The principal reference standards are: UNI 7129, UNI
curva 93° con o senza ispezione. EN 14471 and UNI 11528.
Le principali normative di riferimento sono: UNI 7129,
UNI EN 14471 e UNI 11528.
Tubo essibile PPs PPs flexible pipe
Gli installatori che utilizzano il prodotto OLI hanno affermato Plumbers using this product claim that the PPs flexible pipe
che il tubo essibile PPs è in assoluto il migliore rispetto ad is absolutely the best if compared to other competitors’
altri prodotti della concorrenza. products, and not only because of its technical
characteristics.
Il ex PPs OLI è stato testato, con vari spezzoni inseriti, a
trazione di 30 kg, alla temperatura dichiarata di 120°C e With different clips inserted between them, OLIflex PPs has
alla tenuta in pressione di 5.000 Pa. been tested in tension (30 kg), with a declared temperature
of 120°C and pressure tightness of 5,000 Pa.
Sono stati eseguiti test attraverso i quali è possibile
affermare che la composizione di diversi spezzoni di varie Having successfully passed the test, OLI can affirm there
lunghezze per la realizzazione del tratto verticale, inseriti is no possibility that the several clips (of different lengths)
sia dall’alto sia dal basso e trainati con forza nel cavedio, that compose the vertical section, even if they is inserted
è resistente allo s lamento e non vi è possibilità che gli or from the top or from the bottom and then pulled strongly
elementi escano dalla loro sede. inside the duct, lose tightness or come out from their seat.
30 kg 120°C H1
5000 Pa
