P. 36
OLI ex PPs
Adattatore AISI 316 da Flex A
PPs a rigido D.P. Inox ad aria o B
monoparete inox.
Flex AISI 316 adapter PPs - straight
D.P. inox Air, or single wall inox. 150
D
C
Cod. D A B C
OL0153480 60 80 65 76 1
OL0153481 80 100 85 96 1
OL0153482 100 120 105 116 1
Guarnizione compresa, premontata. - Gasket included, pre-assembled.
Aggiungere fascetta stringitubo. - Add locking band.
Fascetta per adattatore AISI 304.
Locking band for adapter AISI 304. 48
D
Cod. D A
OL0153470 60 80 1
OL0153471 80 100 1
OL0153472 100 120 1
Curva 90° AISI 316. L L
90° elbow AISI 316. D int
40
80 H
80
L 1
D
est H
1
Cod. D D H H L L
int est 1 1
OL0160200CL 60 61 79 133 50 50 6
OL0160201 80 81 96 146 60 50 4
OL0160202 100 101 106 156 60 50 4
Guarnizione compresa, premontata. - Gasket included, pre-assembled.
Aggiungere fascetta stringitubo. - Add locking band.
Terminale con visiera AISI 316.
Terminal with protection.
B
A 100
50
D
Cod. D
int
OL0160860CL 60 6
OL0160861 80 10
OL0160862 100 4
Aggiungere fascetta stringitubo. - Add locking band.
34 www.oli-world.com
