FILTRO FILTRO FLESSIBILE
INCLUSO REMOVIBILE
LE UNITÀ INTERNE
MODELLO AM017ANLDKH /EU AM022ANLDKH /EU AM028ANLDKH/EU AM036ANLDKH /EU AM045ANLDKH /EU AM056ANLDKH /EU AM071ANLDKH /EU
Alimentazione Ф, #, V, Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50
Modalità - HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR HP/HR
Capacità Capacità Raffrescamento kW 1.70 2.20 2.80 3.60 4.50 5.60 7.10
nominale Riscaldamento kW 1.90 2.50 3.20 4.00 5.00 6.30 8.00
Potenza assorbita Raffrescamento W 28.00 30.00 34.00 40.00 51.00 73.00 82.00
nominale Riscaldamento 28.00 30.00 36.00 42.00 46.00 68.00 77.00
Assorbimento
Corrente assorbita Raffrescamento 0.20 0.30 0.30 0.30 0.50 0.60 0.70
nominale Riscaldamento A 0.20 0.30 0.30 0.40 0.40 0.60 0.70
Tipo - Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motore
Output W 69 x 1 69 x 1 69 x 1 69 x 1 84 x 1 84 x 1 84 x 1
3
m /min 5.45 / 4.45 / 3.80 6.00 / 4.19 / 3.80 7.05 / 5.15 / 4.35 8.20 / 6.50 / 4.90 12.50 / 10.00 / 7.50 15.50 / 12.50 / 9.50 18.00 / 14.50 / 11.00
Ventilatore Portata aria Alta / Media / Bassa
l/s 91.00 / 74.00 / 63.00 100.00 / 82.00 / 63.00 118.00 / 86.00 / 73.00 137.00 / 108.00 / 82.00 208.00 / 167.00 / 125.00 258.00 / 208.00 / 158.00 300.00 / 242.00 / 183.00
mmH 2 O 0.00 / 1.00 / 3.00 0.00 / 1.00 / 3.00 0.00 / 1.00 / 3.00 0.00 / 1.00 / 3.00 0.00 / 2.00 / 4.00 0.00 / 2.00 / 4.00 0.00 / 2.00 / 4.00
Pressione statica esterna Min. / Std. / Max.
Pa 0.00 / 9.81 / 29.42 0.00 / 9.81 / 29.42 0.00 / 9.81 / 29.42 0.00 / 9.81 / 29.42 0.00 / 19.61 / 39.23 0.00 / 19.61 / 39.23 0.00 / 19.61 / 39.23
Ф, mm 6.35 6.35 6.35 6.35 6.35 6.35 9.52
Tubazione liquido
Ф, inch 1/4" 1/4" 1/4" 1/4" 1/4" 1/4" 3/8"
Tubazioni Ф, mm 12.70 12.70 12.70 12.70 12.70 12.70 15.88
frigorifere Tubazione gas
Ф, inch 1/2" 1/2" 1/2" 1/2" 1/2" 1/2" 5/8"
Scarico condensa Ф, mm VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25) VP25 (OD 32,ID 25)
Cavi Cavo alimentazione < 20m mm 2 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5 1.5 ~ 2.5
collegamento Cavo comunicazione mm 2 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
Tipo - R410A R410A R410A R410A R410A R410A R410A
Refrigerante
Controllo - EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa EEV inclusa
Pressione sonora Alta / Media / Bassa dB(A) 25 /22 /19 26 / 23 / 19 28 / 24 / 19 31 / 26 / 20 32 / 28 / 25 34 / 30 / 26 34 / 30 / 27
Rumorosità
Potenza sonora Alta / Media / Bassa dB(A) 40 42 44 46 47 49 49
Peso netto kg 14.9 14.9 14.9 15.3 18.8 18.8 22.0
Dimensionali
Dimensioni nette (LxAxP) mm 700 x 199 x 440 700 x 199 x 440 700 x 199 x 440 700 x 199 x 440 900 x 199 x 440 900 x 199 x 440 1100 x 199 x 440
Accessori Pompa sollevamento condensa Pompa interna non prevista non prevista non prevista non prevista non prevista non prevista non prevista
standard
inclusi Filtro aria - Incluso Incluso Incluso Incluso Incluso Incluso Incluso
