P. 32
GAMMA PPECOFORTE
HTR aumenti D /DN 1
1
eccentrici D /DN 1
1
L 2
L 2
Z 1 L
K L L 1
L 1 K
D /DN D /DN
2 2 2 2
Mod. A Mod. B
SISTEMI FOGNATURA
COD. D /D DN / DN Mod. K Z L L L kg HxLxP CL €/pz
1 2 1 2 1 1 2
VSE010921 110/125 100/125 A 4 6 67 49 122 0,221 20 240 970x800x1200 FP02 8,83
VSE010922 110/160 100/150 B 10 - 63 52 81 0,342 1 306 930x800x1200 FP02 11,54
VSE010923 125/160 125/150 B 4 - 64 56 83 0,391 1 350 930x800x1200 FP02 14,72
VSE010924 Ü 125/200 125/200 A 22 53 117 57 227 0,900 1 130 930x800x1200 FP02 79,50
VSE010925 Ü 160/200 150/200 A 18 45 93 77 215 0,900 1 132 930x800x1200 FP02 105,94
VSE010926 Ü 200/250 200/250 A 23 51 124 135 310 1,800 1 36 930x800x1200 FP02 123,59
Ü Pezzo saldato.
HTM tappo chiusura
L
s
D
COD. D s L kg CL €/pz
VSE011201 110 3,2 38 0,081 20 FP02 2,95
VSE011202 125 3,2 42 0,113 10 FP02 5,55
VSE011203 160 4,0 49 0,143 10 FP02 5,89
30
