SISTEMI SISTEMI SCARICO SCARICO
GAMMA TRIPLUS

HTB curva 87°30’
L 2
Z 2
D/DN
87°30'
L 1 Z 1

COD. D DN Z 1 L 1 Z 2 L 2 kg HxLxP CL €/pz

VS0650409 32 30 20 45 19 44 0,024 60 480 3360 1000x800x1200 TP02 2,48
VS0650419 40 40 22 47 25 44 0,054 50 400 2000 1030x800x1200 TP02 2,48
VS0650429 50 50 26 48 30 46 0,072 30 240 1200 1030x800x1200 TP02 3,28
VS0650439 75 70 40 53 43 52 0,177 20 160 480 1015x800x1200 TP02 6,67
VS0650449 90 90 46 56 51 56 0,265 20 80 320 1080x800x1200 TP02 7,40
VS0650459 110 100 57 61 61 59 0,409 20 80 160 940x800x1200 TP02 7,79
VS0650469 125 125 62 66 70 64 0,600 10 40 120 1039x800x1200 TP02 21,36
VS0650479 160 150 - 82 85 77 1,143 1 - 65 930x800x1200 TP02 35,30
VS0650489 200 200 96 115 110 115 2,370 1 - 30 930x800x1200 TP02 164,13
VS0650499 250 250 120 155 140 152 4,812 1 - 14 930x800x1200 TP02 279,63

Curva raggiata 87°30’
L
2
L
1
Z 2
D/DN
87°30’
Z
1
COD. D DN Z L Z L kg HxLxP CL €/pz
1 1 2 2
VS0652901 40 40 25 45 30 43 0,057 50 400 2000 930x800x1200 TP02 2,64
VS0652902 50 50 31 46 37 45 0,079 30 240 1200 930x800x1200 TP02 3,31
VS0652903 75 70 48 56 54 52 0,187 15 180 360 930x800x1200 TP02 6,74
VS0652904 90 90 57 56 64 56 0,253 20 80 240 930x800x1200 TP02 7,56
VS0652905 110 100 69 64 78 59 0,434 20 80 160 930x800x1200 TP02 7,99

65
