SISTEMI SISTEMI SCARICO SCARICO
GAMMA TRIPLUS

HTDA braga doppia L 3
87°30’
D 3 /DN 3 L
87°30’ 87°30’ Z 3
Z 1
D 2 /DN 2
L Z Z L L 1
4 4 2 2
D/DN

COD. D DN L Z L Z L Z L kg HxLxP CL €/pz
1/2/3 1/2/3 1 1 2/4 2/4 3 3
VS0650654 110/50/50 100/50/50 181,5 25 60 63 44 42,5 54 0,399 5 40 120 1000x800x1200 TP02 60,67
VS0650656 110/110/110 100/100/100 249 64 60 72 52 73 52 0,728 5 20 60 1000x800x1200 TP02 60,67
VS0650659 Ü 125/110/110 125/100/100 252 59 65 79 52 72 56 0,814 5 20 60 1010x800x1200 TP02 132,75
VS0650667 Ü 160/110/110 150/100/100 289 61 84 100 52 81 63 1,295 1 - 45 800x800x1200 TP02 236,99
Ü Pezzo saldato.

Braga curvata doppia L L
87°30’ L 2 3 4
Z Z
D /DN 2 3 D /DN
2
2
3 3
Z
1
L 1
D /DN
1 1
COD. D DN Z L Z L Z L L kg HxLxP CL €/pz
1/2/3 1/2/3 1 1 2 2 3 3 4
VS0652910 90/90/75 90/90/70 57 56 64 56 47 56 53 0,531 15 60 120 955x800x1200 TP02 50,65
VS0652911 90/90/90 90/90/90 57 56 64 56 47 56 56 0,531 12 48 96 955x800x1200 TP02 50,65
VS0652912 110/110/75 100/100/70 69 64 78 56 58 59 52 0,649 5 30 60 955x800x1200 TP02 56,27
VS0652913 110/110/90 100/100/90 69 64 78 56 58 59 56 0,684 5 30 60 955x800x1200 TP02 58,33
VS0652914 110/110/110 100/100/100 69 64 78 56 58 59 59 0,806 5 - 60 955x800x1200 TP02 60,67

HTED braga ad
angolo 87°30’ L 3
D 3 /DN 3 L
87°30’ 87°30’ Z 3
Z 1
D 2 /DN 2
L Z Z L L 1
90° 4 4 2 2
D /DN
1 1

COD. D DN Z Z Z L L L L kg HxLxP CL €/pz
1/2/3 1/2/3 1 2/4 3 1 2/4 3
VS0650657 110/110/110 100/100/100 54 77 71 242 63 54 54 0,727 5 20 60 955x800x1200 TP02 63,53
VS0650661 125/110/110 125/100/100 54 77 71 255 71 54 59 0,892 5 20 60 1010x800x1200 TP02 74,22
VS0650662 Ü 160/110/110 150/100/100 68 100 77 290 78 52 67 1,208 1 - 50 800x800x1200 TP02 236,99
Ü Derivazioni saldate.

69
