 Dati tecnici e dimensionali DIMENSIONI IN MM

R553FKDB

O P T

F
G N

H E M

R500Y221 (400x650x85÷130 mm)
G
D R500Y222 (600x650x85÷130 mm)
B
A I I I C R R500Y223 (800x650x85÷130 mm)
L S R500Y224 (1000x650x85÷130 mm)
N° CASSETTA
CODICE A B C D E F G H I L M N O P R S T
STACCHI R500-2
R553FKDB102 - R553FKDB122 2 235 -
R553FKDB103 - R553FKDB123 3 285 50 R500Y221
R553FKDB104 - R553FKDB124 4 335 100
R553FKDB105 - R553FKDB125 5 385 150
R553FKDB106 - R553FKDB126 6 435 200 R500Y222
R553FKDB107 - R553FKDB127 7 149 B.18 36 95 208 108 G 1” 411 50 485 50 179 174 250 53 99 38
R553FKDB108 - R553FKDB128 8 535 300
R553FKDB109 - R553FKDB129 9 585 350 R500Y223
R553FKDB110 - R553FKDB130 10 635 400
R553FKDB111 - R553FKDB131 11 685 450
R553FKDB112 - R553FKDB132 12 735 500 R500Y224

R553FPDB

P
M N S
F
R
G
B
H E O Q
R500Y221 (400x650x85÷130 mm)
G
R500Y222 (600x650x85÷130 mm)
D
B R500Y223 (800x650x85÷130 mm)
A I I I C T R500Y224 (1000x650x85÷130 mm)
L U
N° CASSETTA
CODICE A B C D E F G H I L M N O P Q R S T U
STACCHI R500-2
R553FPDB342 - R553FPDB362 2 258 - 283
R553FPDB343 - R553FPDB363 3 308 50 333 R500Y221
R553FPDB344 - R553FPDB364 4 358 100 383
R553FPDB345 - R553FPDB365 5 408 150 433
R553FPDB346 - R553FPDB366 6 458 200 483 R500Y222
R553FPDB347 - R553FPDB367 7 165 3/4”E 43 95 209 101 G1” 405 50 508 202 250 25 533 100 140 44 47 93
R553FPDB348 - R553FPDB368 8 558 300 583
R553FPDB349 - R553FPDB369 9 608 350 633
R553FPDB350 - R553FPDB370 10 658 400 683 R500Y223
R553FPDB351 - R553FPDB371 11 708 450 733
R553FPDB352 - R553FPDB372 12 758 500 783 R500Y224
