R553DS DIMENSIONI IN MM

P T

F
G N
H
E M

G
D
B
A I I I C R
L S

N° CASSETTA
CODICE G x B A C D E F H I L M N P R S T
STACCHI R500-2
R553DSX042 2 190 110
R553DSX043 3 240 160 R500Y221
R553DSX044 4 290 210
R553DSX045 5 340 260
R553DSX046 6 390 310 R500Y222
R553DSX047 7 1”F x 3/4”E 38 102 61 209 109 379 50 440 50 197 360 49 86 35
R553DSX048 8 490 410
R553DSX049 9 540 460 R500Y223
R553DSX050 10 590 510
R553DSX051 11 640 560
R553DSX052 12 690 610 R500Y224

R580C

L
K Misura
Codice C Ø D E F G I K L
A x B
A B R580CY062
G 82
F
R580CY063 3/4”M x 3/4”F 1/2” 16 23,5 23,5 28,5 45 35 31 117
C Ø
D I I E R580CY064 152
R580CY052 92
R580CY053 1”M x 1”F 3/4” E 18 26 26 33 53 40 38 132
R580CY054 172
L
K
Misura
Codice C D E F G I K L
A x B
A B
G R580CY022 97
F
R580CY023 3/4”M x 3/4”F 32 30 28 46 35 31 132
C
D I E R580CY024 16 167
R580CY042 97
R580CY043 1”M x 1”F 32 30 33 55 35 39 132
R580CY044 167
