P. 134
Curva 45°. L 2
45° elbow. L D
int
45°
100
L
3
100
L
1
D est
Cod. D D L L L L
int est 1 2 3
OL0160181NE 80 81 60 50 70 170 1
OL0160182NE 100 101 60 50 73 177 1
Collare di ssaggio. D
Wall fixing collar.
sp
C
D 1
A
OLI ex nero pellet
B
Tassello AxB Perno CxD Spessore Larghezza Foro muro
Cod. D
AxB anchor CxD pivot Thickness Wide Wall hole
OL0160741NE 80 10x60 M8x200 1,5 25 10 1
OL0160742NE 100 10x60 M8x200 1,5 25 10 1
Raccordo T 90° femmina - femmina D
con tappo per ispezione con int
guarnizione. T200 H1 W. L
TEE 90° lowered for pellet,
derivation female with silicon 100
gasket. T200 H1 W. H tot
D int1
25
D est
Cod. D D D H L
int int1 est tot
OL0160301NE 80 80 81 200 60 1
OL0160302NE 100 80 101 200 60 1
OL0160303NE 100 100 101 200 60 1
