Sistema OLI ex D.P. inox 25 The OLIflex D.P. inox 25 system
Il sistema OLI ex D.P. inox 25 ad elementi modulari a With circular section modular elements and with an
sezione circolare con interposta lana minerale ad alta interposed high density mineral wool the OLIflex D.P.
densità è realizzato con saldatura longitudinale continua inox 25 system is realized with micro plasma continuous
al micro plasma. La parete interna, a contatto con i fumi, longitudinal welding. The inner wall, in contact with the
è realizzata in acciaio Inox AISI 316 L BA, mentre quella smoke, is made of stainless steel AISI 316 L BA, while the
esterna è realizzata in acciaio Inox AISI 304 BA o nelle outer one is made of stainless steel AISI 304 BA or, for
versioni in rame o verniciata rame martellato o verniciata di the customized finishing, of copper, painted hammered
colore scelto dalla mazzetta RAL. copper or painted in one color chosen from the RAL bribe.
OLI ex D.P. inox 25 è stato certi cato per ricevere i fumi OLIflex D.P. inox 25 was certified to receive the smoke from
provenienti da generatori a GAS, gasolio e legna, compreso gas, diesel and wood, including pellets, generators.
il pellet.
UNI and EN norms about smoke discharge systems,
Le norme UNI ed EN, sulle canne fumarie, obbligano require the installation, if they are placed outside a
all’installazione dei sistemi a doppia parete, isolati/ building, of the double-wall type, insulated against
coibentati, se collocati all’esterno di un edi cio, alle weathering. Moreover, the regulations in force require
intemperie. Sempre le normative vigenti impongono to install the systems with double wall, insulated, to
l’obbligo d’installare i sistemi a doppia parete, isolati/ cross floors or roofs made of combustible material.
coibentati, per attraversare solai o tetti realizzati con Generally the insulation, between the inner wall and the
materiale combustibile. outer, is realized with high density 25 mm thick rock
Generalmente la coibentazione, fra la parete interna e wool; however there is the possibility, for generators
quella esterna, è realizzata con lana di roccia ad alta with very high flue gas temperature and on request, to
densità di spessore 25 mm, ma c’è la possibilità, per have a 50 mm or 75 mm thick insulation with rock wool
generatori con temperatura dei fumi molto elevata e su insulation or mixed with ceramic fiber, in contact with
richiesta, di avere la coibentazione di spessore 50 mm the inner wall, and rock wool, in contact with the outer
o 75 mm con lana di roccia o coibentazione mista con wall.
bra ceramica, a contatto con la parete interna e lana di The OLIflex D.P. inox 25 system, from Ø 80/130 mm
roccia, a contatto con la parete esterna. until Ø 200/250 mm does not need safety clamp
Il sistema OLI ex D.P. inox 25, dal Ø 80/130 mm al because, the outer wall is realized with the patented
Ø 200/250 mm non ha bisogno di fascetta di system at welt with four principles, tested in bending,
sicurezza perché, la parete esterna, è realizzata con compression and tension, safe and easy to install.
il sistema, brevettato, a letto con quattro principi, The coupling between modules is done with the glass-
testato a essione, compressione e trazione, sicuro system, male-female and silicone seal, triple lip, already
rame 25
e di facilissima installazione. L’innesto fra i moduli included in the elements.
OLI ex D.P. inox 25
avviene con il sistema a bicchiere, maschio-femmina e For diameters Ø 250/300 mm up to Ø 400/450 mm, the
guarnizione siliconica, a triplo labbro, già inserita negli system is constructed with mechanical seal obtained
elementi. with a safety clamps. The tightness and condensation
Per i diametri Ø 250/300 mm no al Ø 400/450 mm, at the pressure is realized with a silicone gasket to three
il sistema è realizzato con tenuta meccanica ottenuta lips that from Ø 250/300 onwards is placed on the male
con una fascetta di sicurezza. La tenuta alla pressione side of the inner wall.
ed alle condense è realizzata tramite una guarnizione All “OLIflex D.P. inox 25” systems with outer surface in
siliconica a tre labbra che dal Ø 250/300 in poi è posta copper, are produced with snap-on glass system, male
sul lato maschio della parete interna. and female and seat for housing of the safety clamp. It is
Tutti i sistemi “OLI ex D.P. inox 25” realizzati not possible to realize the mechanical seal on the outer
con super cie esterna in rame, sono prodotti con surface of the copper with no safety clamps because
innesto a bicchiere, maschio e femmina e sede of an excess of work which can create cracking on
per l’alloggiamento della fascetta di sicurezza. welding.
Non è possibile realizzare la tenuta meccanica, della The technical and functional features of the OLIflex D.P.
super cie esterna in rame, senza fascetta di sicurezza, inox 25 system are as follows:
a causa di un eccesso di lavorazioni che possono 1. UNI EN 1856/1 T200 - P1 - W - V2 - L50050 - O00
creare delle criccature sulla saldatura. seal.
Le caratteristiche tecnico funzionali del sistema “OLI ex
D.P. inox 25” sono le seguenti: 2.UNI EN 1856/1 T600 - N1 - D - V2 - L50050 - G65
without seal.
1. UNI EN 1856/1 T200 - P1 - W - V2 - L50050 - O00
con guarnizione.
2.UNI EN 1856/1 T600 - N1 - D - V2 - L50050 - G65
senza guarnizione.
