Sistemi e articoli su richiesta System and items upon request
OLI è in grado di rispondere ad ogni esigenza del mercato, OLI is able to satisfy any market needs, therefore offering
proponendo delle soluzioni speciali su richiesta. special solutions upon request.
Di seguito qualche esempio di articoli e sistemi speciali Here are some examples of articles and special system that
che OLI è in grado di realizzare. OLI is able to produce.
De ettore - Deflector
Su richiesta produciamo e forniamo, dal Ø 80 al Ø 400
mm, seguendo le tabelle delle norme DIN. Questi terminali
speciali, in acciaio inox, vengono installati con l’intento
di evitare all’acqua piovana di penetrare all’interno del
condotto fumario e garantire ai fumi o vapori di uscire in
atmosfera.
Upon request OLI produced and supplied special
deflectors, from diameter 80 up to diameter 400, following
the DIN reference tables. This special terminals, in stainless
steel material, are installed to prevent water rain from
entering inside the flue and ensuring, at the same time, the
possibility for the smokes and the steams to go out into the
atmosphere.
Tramogge - Hopper
La tramoggia della foto è solo un esempio per dimostrare le
nostre possibilità. Su richiesta possiamo fornire tramogge
a sezione quadrata o rettangolare, angiate su ambo i lati,
liscie o cartellate in acciaio inox o altri materiali.
The hopper in the photo is only one example of what
OLI can produce. Upon request OLI can supply square
or rectangular section hoppers, flanged on both sides,
smooth or rugged in stainless steel or in other materials
Sistema Coassiale PPs-inox - Coaxial system PPs-inox
Il sistema Coassiale può essere impiegato sia per prelevare
l’aria, comburente, dall’intercapedine fra i due tubi, sia
come cavedio di classe “A1” di reazione al fuoco per
proteggere il PPs, o come sistema a D.P. non isolato per
esterno. Possiamo produrre le seguenti misure: Ø 60/10
Ø 80/125 - Ø 100/150 - Ø 125/180 e Ø 160/210 mm.
In this specific case the coaxial system can be used to take
the air (combustion) off the interspace between the two
pipes, as Class “A1” Cavity of fire reaction to protect the PPs
or as not insulated double wall system for outdoor. OLI can
produce the following sizes: Ø 60/100, Ø 80/125, Ø 100/150,
Ø 125/180 and Ø 160/210
Articoli speciali
System upon request
