Taglia 4202 4502 4802 5202 5602 6002 6402 6503 6703 6903 7203 8403 9603
°,A,L n° 2 2 2 2 2 2 2 3 3 3 3 3 3
Numero E,U n° 2 2 2 2 2 2 2 3 3 3 3 - -
N n° 2 2 2 2 2 2 2 3 - - - - -
°,A,L n° 2 2 2 2 2 2 2 3 3 3 3 3 3
Circuiti E,U n° 2 2 2 2 2 2 2 3 3 3 3 - -
N n° 2 2 2 2 2 2 2 3 - - - - -
Refrigerante °,A,E,L,N,U tipo R1234ze
° kg 52,0 55,0 55,0 63,0 65,0 62,0 70,0 67,0 55,0 78,0 62,0 99,0 112,0
A,L kg 62,0 67,0 67,0 70,0 106,0 82,0 82,0 74,0 81,0 85,0 70,0 106,0 80,0
Carica refrigerante E kg 70,0 89,0 80,0 100,0 113,0 86,0 95,0 77,0 89,0 89,0 100,0 - -
circuito 1 (1)
N kg 92,0 99,0 110,0 114,0 128,0 128,0 138,0 85,0 - - - - -
U kg 70,0 89,0 80,0 85,0 113,0 86,0 95,0 77,0 89,0 89,0 100,0 - -
° kg 59,0 64,0 64,0 70,0 71,0 73,0 80,0 74,0 61,0 85,0 70,0 99,0 112,0
A kg 70,0 78,0 78,0 82,0 106,0 99,0 99,0 81,0 81,0 92,0 75,0 106,0 95,0
Carica refrigerante E kg 85,0 96,0 90,0 110,0 113,0 98,0 97,0 85,0 89,0 96,0 100,0 - -
circuito 2 (1) L kg 70,0 79,0 78,0 82,0 106,0 99,0 99,0 81,0 81,0 92,0 75,0 106,0 95,0
-
-
N U kg 92,0 107,0 110,0 124,0 128,0 138,0 138,0 92,0 89,0 96,0 100,0 - - - -
-
ARIA-ACQUA Carica refrigerante A,L ° kg - - - - - - - - - - - - - - 74,0 65,0 85,0 80,0 106,0 112,0 ARIA-ACQUA
113,0
103,0
85,0
97,0
98,0
90,0
96,0
85,0
kg
99,0
81,0
85,0
81,0
92,0
kg
75,0
E,U
circuito 3 (1)
-
92,0
N kg - - - - - - - - - - - - - - 85,0 89,0 96,0 100,0 - - - -
-
-
kg
Scambiatore lato utenza
Tipo °,A,E,L,N,U tipo Piastre
° n° 1 1 1 1 1 1 1 1 1 1 1 1 1
A,L n° 1 1 1 1 1 1 1 2 2 2 2 2 2
Numero
E,U n° 1 1 1 1 2 2 2 2 2 2 2 - -
N n° 1 2 2 2 2 2 2 2 - - - - -
(1) La carica riportata in tabella è un valore stimato e preliminare. Il valore finale della carica di refrigerante è riportato nella targhetta tecnica dell’unità. Per maggiori informazioni contattare sede.
DATI VENTILATORI
Taglia 1402 1602 1802 2002 2202 2352 2502 2652 2802 3002 3202 3402 3602 3902
Ventilatore
Tipo °,A,E,L,N,U tipo Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale
° n° 6 6 6 8 8 8 8 8 8 10 10 10 10 12
A,L n° 8 8 8 8 10 10 10 12 12 12 12 14 14 16
Numero
E,U n° 8 8 10 10 10 12 12 14 14 14 14 16 16 18
N n° 10 10 12 12 12 14 14 16 16 16 16 18 20 22
Taglia 4202 4502 4802 5202 5602 6002 6402 6503 6703 6903 7203 8403 9603
Ventilatore
Tipo °,A,E,L,N,U tipo Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale Assiale
° n° 12 14 14 16 16 16 18 18 18 20 22 22 22
A,L n° 16 18 18 18 20 22 22 24 24 28 28 30 34
Numero
E,U n° 20 20 22 22 24 26 28 28 30 30 32 - -
N n° 22 26 28 30 32 32 32 34 - - - - -
Maggiorati
Taglia 1402 1602 1802 2002 2202 2352 2502 2652 2802 3002 3202 3402 3602 3902
Ventilatori: M
Ventilatore maggiorato
°,A,U tipo Asincrono
Motore ventilatore
E,L,N tipo Asincrono con taglio di fase
Senza prevalenza
° m³/h 108000 108000 108000 144000 144000 144000 144000 144000 144000 180000 180000 180000 180000 216000
A m³/h 144000 144000 144000 144000 180000 180000 180000 216000 216000 216000 216000 252000 252000 288000
E m³/h 92000 92000 115000 115000 115000 138000 138000 161000 161000 161000 161000 184000 184000 207000
Portata aria
L m³/h 92000 92000 92000 92000 115000 115000 115000 138000 138000 138000 138000 161000 161000 184000
N m³/h 115000 115000 138000 138000 138000 161000 161000 184000 184000 184000 184000 207000 230000 253000
U m³/h 144000 144000 180000 180000 180000 216000 216000 252000 252000 252000 252000 288000 288000 324000
° dB(A) 98,0 98,0 98,0 98,0 98,0 98,0 98,0 98,0 98,0 99,0 99,0 100,0 100,0 101,0
A dB(A) 98,0 98,0 99,0 99,0 99,0 99,0 99,0 100,0 100,0 100,0 100,0 100,0 100,0 101,0
E dB(A) 89,0 89,0 90,0 90,0 90,0 91,0 91,0 92,0 92,0 92,0 92,0 93,0 93,0 93,0
Livello di potenza sonora
L dB(A) 89,0 89,0 89,0 89,0 90,0 91,0 91,0 91,0 91,0 91,0 91,0 91,0 91,0 92,0
N dB(A) 90,0 90,0 91,0 91,0 91,0 91,0 91,0 92,0 92,0 92,0 92,0 93,0 93,0 93,0
U dB(A) 98,0 98,0 99,0 99,0 99,0 100,0 100,0 100,0 100,0 100,0 100,0 101,0 101,0 101,0
