Taglia 4202 4502 4802 5202 5602 6002 6402 6503 6703 6903 7203 8403 9603
Ventilatori: M
Ventilatore maggiorato
°,A,U tipo Asincrono
Motore ventilatore
E,L,N tipo Asincrono con taglio di fase
Senza prevalenza
° m³/h 216000 252000 252000 288000 288000 288000 324000 324000 324000 360000 396000 396000 396000
A m³/h 288000 324000 324000 324000 360000 396000 396000 432000 432000 504000 504000 540000 612000
E m³/h 230000 230000 253000 253000 276000 299000 322000 322000 345000 345000 368000 - -
Portata aria
L m³/h 184000 207000 207000 234000 260000 286000 286000 276000 276000 322000 322000 345000 442000
N m³/h 253000 299000 322000 345000 368000 368000 368000 391000 - - - - -
U m³/h 360000 360000 396000 396000 432000 468000 504000 504000 540000 540000 576000 - -
° dB(A) 101,0 101,0 101,0 102,0 102,0 102,0 102,0 102,0 102,0 103,0 103,0 103,0 103,0
A dB(A) 101,0 101,0 102,0 101,0 102,0 102,0 102,0 103,0 103,0 103,0 103,0 104,0 104,0
E dB(A) 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 95,0 - -
Livello di potenza sonora
L dB(A) 93,0 93,0 93,0 93,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 95,0
N dB(A) 93,0 94,0 94,0 95,0 95,0 95,0 95,0 95,0 - - - - -
U dB(A) 102,0 102,0 102,0 102,0 103,0 103,0 103,0 103,0 103,0 103,0 103,0 - -
Inverter ARIA-ACQUA
Taglia 1402 1602 1802 2002 2202 2352 2502 2652 2802 3002 3202 3402 3602 3902
Ventilatori: J
Ventilatore inverter
Motore ventilatore °,A,E,L,N,U tipo Inverter
° m³/h 96000 96000 96000 128000 128000 128000 128000 144000 144000 180000 180000 180000 180000 216000
A m³/h 128000 128000 128000 128000 160000 160000 160000 192000 192000 192000 192000 224000 224000 256000
E m³/h 92000 92000 115000 115000 115000 138000 138000 161000 161000 161000 161000 184000 184000 207000
Portata aria
L m³/h 92000 92000 92000 92000 115000 115000 115000 138000 138000 138000 138000 161000 161000 184000
N m³/h 115000 115000 138000 138000 138000 161000 161000 184000 184000 184000 184000 207000 230000 253000
U m³/h 128000 128000 160000 160000 160000 192000 192000 224000 224000 224000 224000 256000 256000 288000
Dati sonori calcolati durante il funzionamento a freddo (1)
° dB(A) 97,0 97,0 97,0 98,0 98,0 98,0 98,0 98,0 98,0 99,0 100,0 100,0 100,0 101,0
A dB(A) 97,0 97,0 98,0 98,0 98,0 98,0 98,0 99,0 99,0 99,0 99,0 99,0 99,0 100,0
E dB(A) 89,0 89,0 90,0 90,0 90,0 91,0 91,0 92,0 92,0 92,0 92,0 93,0 93,0 93,0
Livello di potenza sonora
L dB(A) 89,0 89,0 89,0 89,0 90,0 91,0 91,0 91,0 91,0 91,0 91,0 91,0 91,0 92,0

N dB(A) 90,0 90,0 91,0 91,0 91,0 91,0 91,0 92,0 92,0 92,0 92,0 93,0 93,0 93,0
U dB(A) 97,0 97,0 98,0 98,0 98,0 99,0 99,0 99,0 99,0 99,0 99,0 100,0 100,0 100,0
(1) Potenza sonora: calcolata sulla base di misure effettuate in accordo con la normativa UNI EN ISO 9614-2, nel rispetto di quanto richiesto dalla certificazione Eurovent. Pressione sonora misurata in campo libero (in accordo con la UNI EN
ISO 3744).
Taglia 4202 4502 4802 5202 5602 6002 6402 6503 6703 6903 7203 8403 9603
Ventilatori: J
Ventilatore inverter
Motore ventilatore °,A,E,L,N,U tipo Inverter
° m³/h 216000 252000 252000 288000 288000 288000 324000 324000 324000 360000 396000 396000 396000
A m³/h 256000 288000 288000 324000 360000 396000 396000 384000 384000 448000 448000 480000 612000
E m³/h 230000 230000 253000 253000 276000 299000 322000 322000 345000 345000 368000 - -
Portata aria
L m³/h 184000 207000 207000 234000 260000 286000 286000 276000 276000 322000 322000 345000 442000
N m³/h 253000 299000 322000 345000 368000 368000 368000 391000 - - - - -
U m³/h 320000 320000 352000 352000 384000 416000 448000 448000 480000 480000 512000 - -
Dati sonori calcolati durante il funzionamento a freddo (1)
° dB(A) 101,0 101,0 101,0 102,0 102,0 102,0 102,0 102,0 102,0 103,0 103,0 103,0 103,0
A dB(A) 100,0 100,0 101,0 102,0 102,0 102,0 102,0 102,0 102,0 102,0 102,0 103,0 104,0
E dB(A) 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 95,0 - -
Livello di potenza sonora
L dB(A) 93,0 93,0 93,0 93,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 94,0 95,0
N dB(A) 93,0 94,0 94,0 95,0 95,0 95,0 95,0 95,0 - - - - -
U dB(A) 101,0 101,0 101,0 102,0 102,0 102,0 102,0 102,0 102,0 102,0 102,0 - -
(1) Potenza sonora: calcolata sulla base di misure effettuate in accordo con la normativa UNI EN ISO 9614-2, nel rispetto di quanto richiesto dalla certificazione Eurovent. Pressione sonora misurata in campo libero (in accordo con la UNI EN
ISO 3744).
