18 COLLETTORI DI DISTRIBUZIONE “NINO” CON VALVOLE A SFERA
“NINO” DISTRIBUTION MANIFOLDS WITH BALL VALVES
Utilizzabili con cassetta 1810, 1812, 1910P, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1910P, 1920-1930 and 1939-1940 (pag. 342)
1822RCP50
Collettori NINO in ottone
CW617N con valvole a sfera
con uscite 1/2” tenuta piana.
Interasse 50 mm. Filetto fasato
con pretenuta
NINO manifolds made of
CW617N with ball valves with
1/2” ways flat seat. Distance
between centres 50 mm. Selfseal
thread with o-ring
1/2”
FILETTATURA MASCHIO/FEMMINA FASATA
MALE/FEMALE SELF-SEAL THREAD
Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
leva blu/ blue handle
182 0104 3/4”G 2 1/2” 4/32
182 0105 3/4”G 3 1/2” 4/16
182 0106 3/4”G 4 1/2” 4/16
leva rossa/ red handle
182 0107 3/4”G 2 1/2” 4/32
182 0108 3/4”G 3 1/2” 4/16
182 0109 3/4”G 4 1/2” 4/16
1822RCP50 GUIDA ALLE CONNESSIONI
CONNECTION GUIDE
50 50
1249CZ
1248CZ 1715
1665
Per tubo multistrato Per tubo Pe-x Per tubo rame
For multilayer pipe For Pe-x pipe For copper pipe
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
