P. 331
18 COLLETTORI DI DISTRIBUZIONE “MAXIMA CORNER” CON RUBINETTI D’ARRESTO
“MAXIMA CORNER” DISTRIBUTION MANIFOLDS WITH STOP COCKS
50
50
Utilizzabili con cassetta 1810, 1812, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1920-1930 and 1939-1940 (pag. 342)
1/2”
1871K 1871K Ø16 GUIDA ALLE CONNESSIONI
Collettori con rubinetti d’arresto CONNECTION GUIDE
“MAXIMA CORNER“ in ottone
CW617N cromato. Interasse 50 (Cod. 185 0001-185 0002-185 0003-185 0010-185 0011-185 0012)
mm. Filetto fasato con pretenuta 50 50
“MAXIMA CORNER” manifolds
with stop cocks made of
CW617N chrome-plated.
Distance between centres 50
mm. Self-seal thread with o-ring 50 50
1/2” 24x19 fil. 3/4”
16 16 18 1/2”
Ø16
1240K
1716 1233 144 0063
FILETTATURA MASCHIO/FEMMINA FASATA 1635K 1668K 1435K 1235
3/4”
MALE/FEMALE SELF-SEAL THREAD Ø18
Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box Per tubo multistrato Per tubo Pe-x Per tubo rame Tappo
185 0001 3/4”G 2 1/2”(ø16) 1/10 For multilayer pipe For Pe-x pipe For copper pipe Cap
185 0002 3/4”G 3 1/2”(ø16) 1/8 1871K GUIDA ALLE CONNESSIONI
50
50
185 0003 3/4”G 4 1/2”(ø16) 1/8 CONNECTION GUIDE
185 0010 1”G 2 1/2”(ø16) 1/10 (Cod. 185 0004-185 0005-185 0006-185 0013-185 0014-185 0015)
185 0011 1”G 3 1/2”(ø16) 1/8 50 50
185 0012 1”G 4 1/2”(ø16) 1/8
185 0004 3/4”G 2 24 x 19 fil (ø16) 1/10 3/4” 50 50
Ø18
185 0005 3/4”G 3 24 x 19 fil (ø16) 1/8
185 0006 3/4”G 4 24 x 19 fil (ø16) 1/8
24x19 fil.
16
185 0013 1”G 2 24 x 19 fil (ø16) 1/10
185 0014 1”G 3 24 x 19 fil (ø16) 1/8
1/2”
185 0015 1”G 4 24 x 19 fil (ø16) 1/8 Ø16 1632K
185 0007 3/4”G 2 3/4”(ø18) 1/10 Per tubo multistrato
For multilayer pipe
50 50
185 0008 3/4”G 3 3/4”(ø18) 1/8
185 0009 3/4”G 4 3/4”(ø18) 1/8 1871K GUIDA ALLE CONNESSIONI
185 0016 1”G 2 3/4”(ø18) 1/10 CONNECTION GUIDE
185 0017 1”G 3 3/4”(ø18) 1/8 (Cod. 185 0007-185 0008-185 0009-185 0016-185 0017-185 0018)
185 0018 1”G 4 3/4”(ø18) 1/8 24x19 fil. 50 50
16
1632K
Adattatori per tubi multistrato
su attacchi 24x19fil(Ø16) (Set
dado cromato, ogiva ed inserto) Ø18
3/4”
Multilayer pipe adaptors for 144 0104
24x19fil(Ø16) connections (Kit 1241K
of chrome plated nut, ring and 1666K 1716 144 0071
hose insert) 1636K 1436K Per tubo
rame
For copper
24x19 fil. Tappo
16 pipe Cap
Per tubo multistrato Per tubo Pe-x Adattatore per sede piana
For multilayer pipe For Pe-x pipe Flat seat adaptor
Codice Tipo Prezzo € Conf. 50 50
Code Size Price € Unit/Box
144 0256 16 x 2,0 - 24 x 19 fil (ø16) 1/150
144 0257 20 x 2,0 - 24 x 19 fil (ø16) 1/150
Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For brackets and boxes see the paragraph “Mounting guide“ cap. 24
Per tabella giri di serraggio vedi fine del capitolo
For nut tightenings table see end of chapter
24x19 fil.
16
