Page 329 - TIEMME - COMPONENTI IDRAULICI - DELLAFIORE
P. 329
18 COLLETTORI DI DISTRIBUZIONE “MAXIMA” CON RUBINETTI D’ARRESTO
“MAXIMA” DISTRIBUTION MANIFOLDS WITH STOP COCKS
Utilizzabili con cassetta 1810, 1812, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1920-1930 and 1939-1940 (pag. 342)
1877K50 1877K50
Collettore con rubinetto Collettore con rubinetto
d’arresto “MAXIMA” in ottone d’arresto “MAXIMA” in ottone
CW617N cromato con interasse CW617N cromato con interasse
50 mm e attacchi 3/4”x18 50 mm e attacchi 24x19 fil Ø18.
(Eurocono). Filetto fasato con Filetto fasato con pretenuta
pretenuta Manifold with stop cocks
Manifold with stop cocks “MAXIMA” made of CW617N
“MAXIMA” made of CW617N chrome-plated brass. Distance
chrome-plated brass. Distance between centres 50 mm and
between centres 50 mm and 24x19 tpi Ø18. Self-seal thread
3/4”x18 (Euroconus). Self-seal with o-ring
thread with o-ring
24x19 fil.
3/4” 18
18
FILETTATURA MASCHIO/FEMMINA FASATA
FILETTATURA MASCHIO/FEMMINA FASATA MALE/FEMALE SELF-SEAL THREAD
MALE/FEMALE SELF-SEAL THREAD Dotati di dischetti segna utenza da applicare sulla manopola
Dotati di dischetti segna utenza da applicare sulla manopola Using marks included to be applied on the handwheen
Using marks included to be applied on the handwheen Codice Mandata N. vie Uscite Prezzo € Conf.
Codice Mandata N. vie Uscite Prezzo € Conf. Code Delivery Ways Outlets Price € Unit/Box
Code Delivery Ways Outlets Price € Unit/Box 186 0043 3/4” 2 24 x 19 fil (ø18) 1/25
186 0026 3/4” 2 3/4”(ø18) 4/16
186 0041 3/4” 3 24 x 19 fil (ø18) 1/25
186 0011 3/4” 3 3/4”(ø18) 4/16 186 0044 3/4” 4 24 x 19 fil (ø18) 1/20
186 0015 3/4” 4 3/4”(ø18) 4/16
186 0032 1” 2 24 x 19 fil (ø18) 1/25
186 0024 1” 2 3/4”(ø18) 4/16 186 0031 1” 3 24 x 19 fil (ø18) 1/25
186 0013 1” 3 3/4”(ø18) 4/16
186 0029 1” 4 24 x 19 fil (ø18) 1/20
186 0019 1” 4 3/4”(ø18) 4/16
1877K50 GUIDA ALLE CONNESSIONI 1877K50 GUIDA ALLE CONNESSIONI
CONNECTION GUIDE
CONNECTION GUIDE
(cod. 186 0026-186 0011-186 0015-186 0024-186 0013-186 0019) (cod. 186 0043-186 0041-186 0044-186 0032-186 0031-186 0029)
fil.
144 0104
1241K 1243K 144 0104
1666K 1716K 144 0071 1716K 144 0211
1636K 1436K 1666K24
Per tubo rame 1633K 1433K
Per tubo rame
For copper pipe For copper pipe
Per tubo multistrato
For multilayer pipe Tappo Per tubo multistrato Tappo
Per tubo Pe-x Cap For multilayer pipe Cap
For Pe-x pipe
Adattatore per sede piana Per tubo Pe-x Adattatore per sede piana
Flat seat adaptor For Pe-x pipe Flat seat adaptor
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
309
