P. 328
18 COLLETTORI DI DISTRIBUZIONE “MAXIMA” CON RUBINETTI D’ARRESTO
“MAXIMA” DISTRIBUTION MANIFOLDS WITH STOP COCKS
Utilizzabili con cassetta 1810, 1812, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1920-1930 and 1939-1940 (pag. 342)
1866K 1877K36
1868K Collettore con rubinetto
Collettore con rubinetto d’arresto MAXIMA in ottone
CW617N cromato con interasse
d’arresto MAXIMA in ottone 36 mm e attacchi 24x19 fil Ø18.
CW617N cromato con interasse Filetto fasato con pretenuta.
36 mm e attacchi 1/2”x16.
Filetto fasato con pretenuta. Manifold with stop cocks
Manifold with stop cocks “MAXIMA” made of CW617N
chrome-plated brass. Distance
“MAXIMA” made of CW617N between centres 36 mm and
chrome-plated brass. Distance 24x19 tpi Ø18. Self-seal thread
between centres 36 mm and with o-ring.
1/2”x16. Self-seal thread with
o-ring. 24x19 fil.
18
1/2”
16
FILETTATURA MASCHIO/FEMMINA FASATA
MALE/FEMALE SELF-SEAL THREAD
FILETTATURA MASCHIO/FEMMINA FASATA
MALE/FEMALE SELF-SEAL THREAD Dotati di dischetti segna utenza da applicare sulla manopola
Using marks included to be applied on the handwheen
Dotati di dischetti segna utenza da applicare sulla manopola
Using marks included to be applied on the handwheen Codice Mandata N. vie Uscite Prezzo € Conf.
Codice Mandata N. vie Uscite Prezzo € Conf. Code Delivery Ways Outlets Price € Unit/Box
Code Delivery Ways Outlets Price € Unit/Box 186 0023 3/4”G 2 24 x 19 fil (ø18) 1/25
186 0163 3/4”G 1 1/2”(ø16) 4/32 186 0018 3/4”G 3 24 x 19 fil (ø18) 1/25
186 0008 3/4”G 2 1/2”(ø16) 4/32 186 0014 3/4”G 4 24 x 19 fil (ø18) 1/25
186 0005 3/4”G 3 1/2”(ø16) 4/16 186 0016 3/4”G 5 24 x 19 fil (ø18) 1/20
186 0004 3/4”G 4 1/2”(ø16) 4/16 186 0085 3/4”G 6 24 x 19 fil (ø18) 1/15
186 0010 3/4”G 5 1/2”(ø16) 4/16
186 0006 1”G 2 24 x 19 fil (ø18) 1/25
186 0083 3/4”G 6 1/2”(ø16) 4/12
186 0003 1”G 3 24 x 19 fil (ø18) 1/25
186 0164 1”G 1 1/2”(ø16) 4/32 186 0002 1”G 4 24 x 19 fil (ø18) 1/20
186 0022 1”G 2 1/2”(ø16) 4/32 186 0001 1” G 5 24 x 19 fil (ø18) 1/20
186 0021 1”G 3 1/2”(ø16) 4/16 186 0086 1” G 6 24 x 19 fil (ø18) 1/15
186 0020 1”G 4 1/2”(ø16) 4/16
186 0028 1” G 5 1/2”(ø16) 4/16 186 0138 1”1/4G 2 24 x 19 fil (ø18) 1/20
186 0139 1”1/4G 3 24 x 19 fil (ø18) 1/20
186 0084 1” G 6 1/2”(ø16) 4/12
186 0140 1”1/4G 4 24 x 19 fil (ø18) 1/15
Nuovo codice/ new code
186 0141 1”1/4G 5 24 x 19 fil (ø18) 1/15
186 0142 1”1/4G 6 24 x 19 fil (ø18) 1/10
Nuovo codice/ new code
1866K-1868K GUIDA ALLE CONNESSIONI 1877K36 GUIDA ALLE CONNESSIONI
CONNECTION GUIDE
CONNECTION GUIDE
fil.
144 0104
1240K 1243K 144 0211
1668K 1716 1233 144 0063 1633K 1666K24 1433K 1716K Per tubo rame
1235
1635K 1435K For copper pipe
Per tubo multistrato Tappo
For multilayer pipe Cap
Per tubo multistrato Per tubo Pe-x Per tubo rame Tappo Per tubo Pe-x Adattatore per sede piana
For multilayer pipe For Pe-x pipe For copper pipe Cap For Pe-x pipe Flat seat adaptor
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
308 For pricelist scan the QR code
