P. 342
18 COLLETTORI DI DISTRIBUZIONE “LINEARE”
“LINEARE” DISTRIBUTION MANIFOLDS
Utilizzabili con cassetta 1810, 1812, 1910P, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1910P, 1920-1930 and 1939-1940 (pag. 342)
1912CP 1912CP50R
1922CP Collettore “LINEARE” in ottone
Collettore “LINEARE” in ottone giallo CW617N con interasse 50
mm con uscite 1/2” sede piana.
CW617N con interasse 36 mm Filetto fasato con pretenuta
con uscite 1/2” sede piana
“LINEARE” manifold made “LINEARE” manifold made of
CW617N brass yellow with
of CW617N brass. Distance 1/2” flat male ways. Distance
between centres 36 mm with between centres 50 mm. Self-
1/2” flat male seal thread with o-ring
1/2”
1/2”
Codice Mandata N. vie Uscite Prezzo € Conf. FILETTATURA MASCHIO/FEMMINA FASATA
Code Delivery Ways Outlets Price € Unit/Box MALE/FEMALE SELF-SEAL THREAD
191 0053 3/4”G 2 1/2” 1/50 Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
191 0036 3/4”G 3 1/2” 1/40
191 0249 3/4”G 2 1/2” 1/50
191 0043 3/4”G 4 1/2” 1/35 191 0250 3/4”G 3 1/2” 1/35
191 0243 3/4”G 5 1/2” 1/25
191 0251 3/4”G 4 1/2” 1/25
191 0059 1”G 2 1/2” 1/40
191 0045 1”G 3 1/2” 1/30
191 0060 1”G 4 1/2” 1/25
1912CP GUIDA ALLE CONNESSIONI 1912CP50R GUIDA ALLE CONNESSIONI
1922CP CONNECTION GUIDE CONNECTION GUIDE
50 50
1249CZ
1249CZ 1248CZ 1715
1248CZ 1715 1665
1665
Per tubo multistrato Per tubo Pe-x Per tubo rame Per tubo multistrato Per tubo Pe-x Per tubo rame
For multilayer pipe For Pe-x pipe For copper pipe For multilayer pipe For Pe-x pipe For copper pipe
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
322 For pricelist scan the QR code
