P. 344
18 COLLETTORI DI DISTRIBUZIONE “LINEARE”
“LINEARE” DISTRIBUTION MANIFOLDS
Utilizzabili con cassetta 1940 (pag. 342)
Use with box 1940 (pag. 342)
1915R 1636N06
Collettore “LINEARE“ in ottone Adattatore per corpi con attacco
CW617N, con interasse 65 mm 1”x24 per tubo multistrato
e uscite 1”(ø24). Filetto fasato Adapter for fittings with 1”x24
con pretenuta. connection for multilayer pipe
“LINEARE” manifold made
of CW617N brass, Distance
between centres 65 mm with 1” 24
1”(ø24). Self-seal thread with
o-ring.
1”
24
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box
144 0239 16 x 2,0 - 1”(ø24) 10/150
FILETTATURA MASCHIO/FEMMINA FASATA 144 0240 20 x 2,0 - 1”(ø24) 10/150
MALE/FEMALE SELF-SEAL THREAD
Codice Mandata N. vie Uscite Prezzo € Conf. 144 0241 26 x 3,0 - 1”(ø24) 10/150
Code Delivery Ways Outlets Price € Unit/Box
191 0428 1”1/4G 3 1”(ø24) 1/15
191 0429 1”1/4G 4 1”(ø24) 1/10
Guscio di coibentazione per
1915RISOL ■
collettore di distribuzione
interasse 65 mm art. 1915R
Insulation shell for distribution
manifold distance beteween
centres 65 mm art. 1915R
Codice N. vie Tipo Prezzo € Conf.
Code Ways Size Price € Unit/Box
557 0686 3 1”1/4 1/2
557 0687 4 1”1/4 1/2
1915R GUIDA ALLE CONNESSIONI
CONNECTION GUIDE
65 65
1"
Ø 24
1636N06
Per tubo multistrato
For multilayer pipe
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
