18 COLLETTORI DI DISTRIBUZIONE “LINEARE”
“LINEARE” DISTRIBUTION MANIFOLDS
Utilizzabili con cassetta 1810, 1812, 1910P, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1910P, 1920-1930 and 1939-1940 (pag. 342)
1130CZ
Collettore “LINEARE” 3/4” in
ottone CW602N con interasse
50 mm e uscite 1/2”x15
“LINEARE” manifold made
of CW602N brass, Distance
between centres 50 mm with
1/2”x15
1/2”
15
RESISTENTE ALLA DEZINCIFICAZIONE
DEZINCIFICATION RESISTANT
Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
116 0003 3/4”G 2 1/2”(ø15) 1/50
116 0002 3/4”G 3 1/2”(ø15) 1/35
116 0001 3/4”G 4 1/2”(ø15) 1/25
1130CZ GUIDA ALLE CONNESSIONI
CONNECTION GUIDE
1015
1694 1014 1147CZ
1631GCZ 1149CCZ 1014
Per tubo multistrato Per tubo Pe-x Per tubo rame
For multilayer pipe For Pe-x pipe For copper pipe
Per tabella giri di serraggio vedi fine del capitolo Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For nut tightenings table see end of chapter For brackets and boxes see the paragraph “Mounting guide“ cap. 24
326 For pricelist scan the QR code
