18 COLLETTORI DI DISTRIBUZIONE “LINEARE”
“LINEARE” DISTRIBUTION MANIFOLDS

Utilizzabili con cassetta 1810, 1812, 1910P, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1910P, 1920-1930 and 1939-1940 (pag. 342)

1932 1953
1942 1963
Collettore “LINEARE” in ottone Collettore “LINEARE” in ottone
CW617N con interasse 36 mm e CW617N con interasse 36 mm e
uscite 1/2” femmina uscite per tubo Pe-x
“LINEARE” manifold made “LINEARE” manifold made
of CW617N brass. Distance of CW617N brass. Distance
between centres 36 mm with between centres 36 mm with
1/2” female Pe-x pipe
1/2” Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
191 0064 3/4”G 3 12 x 2,0 1/35
191 0006 3/4”G 3 15 x 2,5 1/35
Codice Mandata N. vie Uscite Prezzo € Conf. 191 0010 3/4”G 3 16 x 2,0 1/35
Code Delivery Ways Outlets Price € Unit/Box
191 0052 3/4”G 2 1/2” 1/45 191 0025 3/4”G 3 16 x 2,2 1/35
191 0050 3/4”G 3 16 x 2,3 1/35
191 0039 3/4”G 3 1/2” 1/40
191 0038 3/4”G 4 1/2” 1/30 191 0092 1”G 3 15 x 2,5 1/25
191 0074 1”G 3 16 x 2,0 1/25
191 0061 1”G 2 1/2” 1/40
191 0023 1”G 3 1/2” 1/30 191 0047 1”G 3 16 x 2,2 1/25
191 0058 1”G 3 16 x 2,3 1/25
191 0048 1”G 4 1/2” 1/20
Nichelato/ Nickel-plated
191 0071 3/4”G 2 1/2” 1/45
191 0069 3/4”G 3 1/2” 1/40 1954
1964
191 0076 3/4”G 4 1/2” 1/30 Collettore “LINEARE” in ottone
CW617N con interasse 36 mm e
191 0082 1”G 2 1/2” 1/40 uscite per tubo Pe-x
191 0077 1”G 3 1/2” 1/30 “LINEARE” manifold made
of CW617N brass. Distance
191 0078 1”G 4 1/2” 1/20 between centres 36 mm with
Pe-x pipe
Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
1952 191 0009 3/4”G 4 15 x 2,5 1/30
1962 191 0012 3/4”G 4 16 x 2,0 1/30
Collettore “LINEARE” in ottone
CW617N con interasse 36 mm e 191 0030 3/4”G 4 16 x 2,2 1/30
uscite per tubo Pe-x 191 0044 3/4”G 4 16 x 2,3 1/30
“LINEARE” manifold made
of CW617N brass. Distance
between centres 36 mm with 191 0093 1”G 4 15 x 2,5 1/20
Pe-x pipe 191 0073 1”G 4 16 x 2,0 1/20
Codice Mandata N. vie Uscite Prezzo € Conf. 191 0040 1”G 4 16 x 2,2 1/20
Code Delivery Ways Outlets Price € Unit/Box
191 0013 3/4”G 2 15 x 2,5 1/45 191 0054 1”G 4 16 x 2,3 1/20
191 0019 3/4”G 2 16 x 2,0 1/45
191 0033 3/4”G 2 16 x 2,2 1/45
191 0056 3/4”G 2 16 x 2,3 1/45

191 0091 1”G 2 15 x 2,5 1/35
191 0075 1”G 2 16 x 2,0 1/35
191 0057 1”G 2 16 x 2,2 1/35
191 0062 1”G 2 16 x 2,3 1/35

Per staffe e cassette vedi paragrafo “Guida al montaggio“ cap. 24
For brackets and boxes see the paragraph “Mounting guide“ cap. 24
