aquatherm blue pipe T

T ridotto - Saldatura a tasca / di testa Materiale: fusiolen® PP-R
Standard: DIN 16962, DIN EN ISO 15874
Colore: verde
Articolo no. D d1 l D1 L z kg Conf. GP Prezzo [€]
Derivazione: saldatura a tasca
L
d1
D1
SDR 11
z
l
1064160074 160,0 75,0 122,0 100,0 460,0 92,0 3,140 1 B 183,39
1064160076 160,0 90,0 125,0 120,0 460,0 92,0 3,176 1 B 190,28
D 1064160078 * 160,0 125,0 120,0 167,0 290,0 80,0 2,842 1 B 198,71
*stampato ad iniezione
Attualmente è in corso un cambiamento dei componenti XXL, che prevede la sostituzione dalla precedente versione (componenti realizzati
con segmenti saldati) con la nuova versione stampata ad iniezione.
Tutti i componenti che sono convertiti alla produzione di stampaggio ad iniezione sono comunque ordinabili su richiesta come pezzi
speciali con segmenti saldati. Per questi articoli speciali non vengono assegnati dei numero di articolo.
Prestare attenzione! Non è possibile saldare elettromanicotti direttamente su raccordi stampati ad iniezione. L‘utilizzo dell‘elettromanicotto
è consentito previa saldatura di un tronchetto di tubo alle estremità del raccordo. Il tronchetto di tubo dovrà avere una lunghezza tale da
permettere la saldatura con l‘elettromanicotto.
T ridotto - Saldatura a tasca Materiale: fusiolen® PP-R
Standard: DIN 16962, DIN EN ISO 15874
Colore: blu / verde
Articolo no. D d1 l D1 L z kg Conf. GP Prezzo [€]
Derivazione: saldatura a tasca
L
D1
d1
SDR 11
z
l 2064200020 200,0 75,0 142,0 100,0 500,0 112,0 5,460 1 B 166,34
2064200021 200,0 90,0 145,0 120,0 500,0 112,0 5,580 1 B 155,53
2064200022 200,0 110,0 149,0 147,0 500,0 112,0 5,810 1 B 157,31
D
2064200023 200,0 125,0 155,0 167,0 500,0 115,0 6,100 1 B 176,50
2064250025 250,0 75,0 167,0 100,0 750,0 137,0 12,440 1 B 284,80
2064250026 250,0 90,0 170,0 120,0 750,0 137,0 12,420 1 B 286,25
2064250027 250,0 110,0 174,0 147,0 750,0 137,0 12,760 1 B 291,90
2064250028 250,0 125,0 180,0 167,0 750,0 140,0 13,030 1 B 346,41
2064315031 315,0 125,0 213,0 167,0 920,0 173,0 25,000 1 B 527,02
2064355035 355,0 125,0 233,0 167,0 960,0 193,0 32,500 1 B 655,84
2064400040 400,0 125,0 255,0 167,0 1.000,0 215,0 42,100 1 B 966,80
2064450046 450,0 125,0 280,0 167,0 1.050,0 240,0 55,700 1 B 1.277,86
SDR 17,6
2067160060 160,0 75,0 122,0 100,0 460,0 92,0 2,227 1 B 88,12
2067160061 160,0 90,0 125,0 120,0 460,0 92,0 2,364 1 B 88,17
2067160062 * 160,0 125,0 120,0 167,0 290,0 80,0 2,309 1 B 127,12
2067200063 200,0 75,0 142,0 100,0 500,0 112,0 3,620 1 B 127,58
2067200064 200,0 90,0 145,0 120,0 500,0 112,0 3,742 1 B 132,72
2067200065 200,0 110,0 149,0 147,0 500,0 112,0 3,976 1 B 133,83
2067200066 200,0 125,0 155,0 167,0 500,0 115,0 4,269 1 B 162,17
2067250068 250,0 75,0 167,0 100,0 750,0 137,0 8,149 1 B 199,38
2067250069 250,0 90,0 170,0 120,0 750,0 137,0 8,274 1 B 208,11
2067250070 250,0 110,0 174,0 147,0 750,0 137,0 8,504 1 B 214,15
2067250071 250,0 125,0 180,0 167,0 750,0 140,0 9,000 1 B 233,33
2067315074 315,0 125,0 213,0 167,0 920,0 173,0 17,570 1 B 355,57
2067355078 355,0 125,0 233,0 167,0 960,0 193,0 21,500 1 B 430,93
2067400083 400,0 125,0 255,0 167,0 1.000,0 215,0 27,690 1 B 576,04
2067450089 450,0 125,0 280,0 167,0 1.050,0 240,0 36,470 1 B 740,06
2067500096 500,0 125,0 305,0 167,0 1.200,0 265,0 51,250 1 B 1.012,72
2067630104 630,0 125,0 370,0 167,0 1.330,0 330,0 89,170 1 B 1.934,83
tubo con riduzione / *stampato ad iniezione con giunto a sella

Pagina 72
