Giunti aquatherm blue pipe

Giunto filettato femmina Materiale: fusiolen® PP-R / ottone o acciaio inox D
SDR 6 / 7,4 / 9 / 11 - con sede esagonale esterna; ottone o *acciaio inox Standard: DIN 16962, DIN EN ISO 15874 d
Colore:
verde
Articolo no. d l D L z z1 R SW kg Conf. GP Prezzo [€]
Saldatura a tasca da un lato l
1070020008 20 34,5 38,5 50,5 36,0 10,0 1/2“ 24 0,078 10 A 9,17 L z
1070020009 20 29,0 43,5 50,0 35,5 10,0 3/4“ 31 0,112 10 A 11,23
1070025010 25 36,0 38,5 52,0 36,0 10,0 1/2“ 24 0,081 10 A 9,17 z 1
1070025011 25 29,0 43,5 50,0 34,0 10,0 3/4“ 31 0,109 10 A 11,23 R SW
1070032012 32 32,0 43,5 53,0 35,0 10,0 3/4“ 31 0,114 5 A 11,60
1070032013 32 37,5 60,0 59,5 41,5 14,0 1“ 39 0,239 5 A 20,32
1070040014 40 40,0 60,0 62,0 41,5 14,0 1“ 39 0,227 5 A 22,54
1070040015 40 40,0 74,0 63,0 42,5 15,0 1 1/4“ 50 0,385 5 A 38,46
1070050016 50 43,0 74,0 66,0 42,5 15,0 1 1/4“ 50 0,404 5 A 38,07
1070050017 50 45,0 85,5 67,0 43,5 15,0 1 1/2“ 55 0,418 5 A 42,66
1070063018 63 51,5 84,0 73,5 46,0 15,0 1 1/2“ 55 0,442 1 A 42,66
1070063019 63 51,0 101,0 77,0 49,5 19,0 2“ 67 0,600 1 A 69,84
1070075020 75 51,0 100,0 77,0 47,0 19,0 2“ 67 0,608 1 A 69,84

1070032066 * 32 37,5 60,0 59,5 41,5 14,0 1“ 39 0,232 1 A 60,75
1070040067 * 40 40,0 60,0 62,0 41,5 14,0 1“ 39 0,219 1 A 61,19
1070040068 * 40 40,0 74,0 63,0 42,5 15,0 1 1/4“ 50 0,331 1 A 95,98
1070050069 * 50 43,0 74,0 66,0 42,5 15,0 1 1/4“ 50 0,351 1 A 96,44 D
d
1070050070 * 50 45,0 84,0 67,0 43,5 15,0 1 1/2“ 55 0,445 1 A 118,58
1070063071 * 63 51,5 84,0 73,5 46,0 15,0 1 1/2“ 55 0,425 1 A 123,51
1070063072 * 63 51,0 101,0 77,0 49,5 19,0 2“ 67 0,196 1 A 276,41
*acciaio inox L z

Giunto filettato maschio Materiale: DIN 16962, DIN EN ISO 15874 z 2
fusiolen® PP-R / ottone
Standard:
SDR 6 / 7,4 / 11 - piano, pre-guarnito Colore: verde R
Articolo no. d d1 d2 D L z z2 R kg Conf. GP Prezzo [€]
Saldatura a tasca da un lato
1070020051 20 21,0 14,0 38,5 52,5 38,0 12,0 1/2“ 0,090 10 A 9,05
1070025052 25 21,0 14,0 38,5 54,0 38,0 12,0 1/2“ 0,078 10 A 9,20
1070025053 25 26,5 18,0 38,5 53,5 37,5 13,0 3/4“ 0,085 10 A 10,68

Giunto filettato maschio Materiale: fusiolen® PP-R / ottone o acciaio inox
SDR 6 / 7,4 / 9 / 11 - piano; ottone o *acciaio inox Standard: DIN 16962, DIN EN ISO 15874 D
verde
Colore:
d
Articolo no. d D L z z2 R kg Conf. GP Prezzo [€]
Saldatura a tasca da un lato
1070020022 20 38,5 56,5 42,0 16,0 1/2“ 0,084 10 A 7,66
1070020023 20 38,5 57,5 43,0 17,0 3/4“ 0,109 10 A 10,06 L z
1070025024 25 38,5 58,0 42,0 16,0 1/2“ 0,085 10 A 8,16
1070025025 25 38,5 57,5 41,5 17,0 3/4“ 0,090 10 A 10,17 z 2
1070032026 32 38,5 59,5 41,5 17,0 3/4“ 0,095 5 A 11,71 R

1070020074 * 20 38,5 56,5 42,0 16,0 1/2“ 0,096 1 A 30,54
1070020075 * 20 38,5 57,5 43,0 17,0 3/4“ 0,108 1 A 35,32
1070025076 * 25 38,5 58,0 42,0 16,0 1/2“ 0,098 1 A 30,54
1070025077 * 25 38,5 57,5 41,5 17,0 3/4“ 0,108 1 A 35,32
1070032078 * 32 38,5 59,5 41,5 17,0 3/4“ 0,115 1 A 36,63
*acciaio inox
