MVA_C1
MVA220C1 MVA280C1 MVA360C1 MVA450C1 MVA500C1
Unità interna
A mm 987 987 987 987 987
B mm 385 385 385 385 385
C mm 178 178 178 178 178
D mm 1307 1307 1307 1307 1307
E mm 501 501 501 501 501
F mm 310 310 310 310 310
Peso netto kg 20,0 20,0 20,0 21,0 21,0
Peso per trasporto kg 27,0 27,0 27,0 29,0 29,0
MVA_F

MVA280F MVA281F MVA360F MVA361F MVA500F MVA501F MVA561F MVA630F MVA631F MVA710F
Unità interna
A mm 1220 870 1220 870 1220 870 870 1420 1200 1420
B mm 225 235 225 235 225 235 235 245 235 245
C mm 700 665 700 665 700 665 665 700 665 700
D mm 1343 973 1343 973 1343 973 973 1548 1303 1548
E mm 315 300 315 300 315 300 300 345 300 345

F mm 823 770 823 770 823 770 770 828 770 828
Peso netto kg 40,0 24,0 40,0 24,0 40,0 25,0 25,0 50,0 32,0 50,0
Peso per trasporto kg 49,0 29,0 49,0 29,0 49,0 30,0 30,0 58,0 38,0 58,0
MVA711F MVA900F MVA901F MVA1120F MVA1121F MVA1250F MVA1251F MVA1400F MVA1401F MVA1601F
Unità interna
A mm 1200 1420 1200 1700 1570 1700 1570 1700 1570 1570
B mm 235 245 235 245 235 245 235 245 235 235

C mm 665 700 665 700 665 700 665 700 665 665
D mm 1303 1548 1303 1828 1669 1828 1669 1828 1669 1669
E mm 300 345 300 345 300 345 300 345 300 300
F mm 770 828 770 828 770 828 770 828 770 770
Peso netto kg 32,0 50,0 33,0 60,0 41,0 60,0 41,0 60,0 43,0 43,0
Peso per trasporto kg 38,0 58,0 39,0 68,0 48,0 68,0 48,0 68,0 50,0 50,0
MVA_FS

MVA220FS MVA280FS MVA360FS MVA450FS MVA500FS
Unità interna
A mm 700 700 700 700 700
B mm 215 215 215 215 215
C mm 600 600 600 600 600
D mm 780 780 780 780 780
E mm 285 285 285 285 285
F mm 682 682 682 682 682

Peso netto kg 16,0 16,0 16,0 16,0 16,0
Peso per trasporto kg 19,0 19,0 19,0 19,0 19,0
MVA_V
MVA1000V MVA1400V
Unità interna
A mm 580 580

B mm 400 400
C mm 1870 1870
D mm 738 738
E mm 545 545
F mm 2083 2083
Peso netto kg 54,0 57,0
Peso per trasporto kg 74,0 77,0

MVA_ERV
MVA500ERV MVA800ERV MVA1000ERV
Dimensioni e pesi
A mm 1700 1800 1800
B C mm 880 1185 1185
mm
390
390
340
SISTEMI VRF D E mm 1988 2110 2110 SISTEMI VRF
1138
1440
mm
1440
F
567
567
535
kg
Peso netto mm 120,0 158,0 158,0
Peso per trasporto kg 175,0 225,0 225,0
