MVA_WL
MVA220WL MVA280WL MVA360WL MVA450WL MVA500WL MVA560WL MVA630WL MVA710WL
Unità interna
A mm 845 845 845 970 970 1078 1078 1078
B mm 209 209 209 224 224 246 246 246
C mm 289 289 289 300 300 325 325 325
D mm 976 976 976 1096 1096 1203 1203 1203
E mm 281 281 281 320 320 350 350 350
F mm 379 379 379 383 383 413 413 413
Peso netto kg 11,0 11,0 11,0 13,0 13,0 16,0 16,0 16,0
Peso per trasporto kg 13,0 13,0 13,0 16,0 16,0 19,0 19,0 19,0
MVA_D

MVA221D MVA251D MVA281D MVA321D MVA361D MVA401D MVA451D MVA501D MVA561D
Unità interna
A mm 710 710 710 710 710 1010 1010 1010 1010
B mm 462 462 462 462 462 462 462 462 462
C mm 200 200 200 200 200 200 200 200 200
D mm 1008 1008 1008 1008 1008 1308 1308 1308 1308
E mm 568 568 568 568 568 568 568 568 568

F mm 275 275 275 275 275 275 275 275 275
Peso netto kg 19,0 19,0 19,0 19,0 19,0 25,0 25,0 25,0 25,0
Peso per trasporto kg 24,0 24,0 24,0 24,0 24,0 31,0 31,0 31,0 31,0
MVA631D MVA711D MVA801D MVA901D MVA1001D MVA1121D MVA1251D MVA1401D
Unità interna
A mm 1010 1310 1200 1340 1340 1340 1340 1340
B mm 462 462 655 655 655 655 655 655

C mm 200 200 260 260 260 260 260 260
D mm 1308 1608 1448 1588 1588 1588 1588 1588
E mm 568 568 858 858 858 858 858 858
F mm 275 275 315 315 315 315 315 315
Peso netto kg 25,0 31,0 39,0 46,0 46,0 46,0 47,0 47,0
Peso per trasporto kg 31,0 38,0 48,0 55,0 55,0 55,0 56,0 56,0
MVA_DH

MVA221DH MVA251DH MVA281DH MVA321DH MVA361DH MVA401DH
Unità interna
A mm 700 700 700 700 700 700
B mm 700 700 700 700 700 700
C mm 300 300 300 300 300 300
D mm 897 897 897 897 897 897
E mm 808 808 808 808 808 808
F mm 362 362 362 362 362 362

Peso netto kg 32,0 32,0 32,0 32,0 32,0 34,0
Peso per trasporto kg 38,0 38,0 38,0 38,0 38,0 40,0
MVA451DH MVA501DH MVA561DH MVA631DH MVA711DH MVA801DH
Unità interna
A mm 700 700 1000 1000 1000 1000
B mm 700 700 700 700 700 700
C mm 300 300 300 300 300 300

D mm 897 897 1205 1205 1205 1205
E mm 808 808 813 813 813 813
F mm 362 362 360 360 360 360
Peso netto kg 34,0 34,0 43,0 43,0 43,0 43,0
Peso per trasporto kg 40,0 40,0 49,0 49,0 49,0 49,0
MVA901DH MVA1001DH MVA1121DH MVA1251DH MVA1401DH MVA1601DH
Unità interna

A mm 1400 1400 1400 1400 1400 1400
B mm 700 700 700 700 700 700
C mm 300 300 300 300 300 300
D mm 1601 1601 1601 1601 1678 1678
E mm 813 813 813 813 808 808
365
365
365
F Peso netto mm 57,0 57,0 365 57,0 57,0 57,0
365
365
SISTEMI VRF Peso per trasporto kg 64,0 64,0 64,0 64,0 67,0 67,0 SISTEMI VRF
kg
57,0
