SISTEMI SISTEMI SCARICO SCARICO
GAMMA HDPE
Braga a sfera doppia D/DN
180° 2 derivazioni 88°30’ 88°30’
K 3 S S 1
L 3
D 1 /DN 1
H
L 1
K 1 K 2
L
2
COD. D/D DN/DN S S H L /L L K /K K kg HxLxP CL €/pz
1 1 1 1 3 2 1 3 2
VS0318001 110/50 100/50 4,3 3 220 105 120 15 15 0,451 5 20 80 1050x800x1200 PE02 49,54
VS0318002 110/56 100/56 4,3 3 220 105 120 15 15 0,473 5 20 80 1050x800x1200 PE02 49,54
VS0318003 110/75 100/70 4,3 3 220 105 120 15 15 0,455 5 20 80 1050x800x1200 PE02 49,54
VS0318004 110/90 100/90 4,3 3,5 220 105 120 15 15 0,477 5 20 80 1050x800x1200 PE02 49,54
VS0318005 110/110 100/100 4,3 4,3 220 105 120 15 15 0,502 5 20 80 1050x800x1200 PE02 49,54
VS0318007 125/50 125/50 4,8 3 220 110 125 15 15 0,556 5 20 80 1050x800x1200 PE02 55,46
VS0318008 125/56 125/56 4,8 3 220 110 125 15 15 0,502 5 20 80 1050x800x1200 PE02 55,46
VS0318009 125/75 125/70 4,8 3 220 110 125 15 15 0,592 5 20 80 1050x800x1200 PE02 55,46
VS0318010 125/90 125/90 4,8 3,5 220 110 125 15 15 0,600 5 20 80 1210x800x1200 PE02 55,46
VS0318011 125/110 125/100 4,8 4,3 220 110 125 15 25 0,610 5 20 60 1054x800x1200 PE02 55,46
VS0318013 125/125 125/125 4,8 4,9 220 110 125 15 25 0,677 5 20 80 1210x800x1200 PE02 55,46
VS0318050 160/110 150/100 6,2 4,3 275 137,5 165 50 50 1,155 1 - 35 930x800x1200 PE02 127,05
VS0318060 160/160 150/150 6,2 6,2 275 137,5 165 50 50 0,950 1 - - 930x800x1200 PE02 173,78
Derivazione saldata.
Braga a sfera 90° D/DN
3 derivazioni 88°30’ 88°30’
S S 1
K 3
L 3
D 1 /DN 1
H
L 1 K
K 1 2
L
2
COD. D/D DN/DN S S H L /L L K /K K kg HxLxP CL €/pz
1 1 1 1 3 2 1 3 2
VS0320001 110/50 100/50 4,3 3 220 105 120 15 15 0,315 5 20 80 1050x800x1200 PE02 57,93
VS0320002 110/56 100/56 4,3 3 220 105 120 15 15 0,476 5 20 80 1210x800x1200 PE02 57,93
VS0320003 110/75 100/70 4,3 3 220 105 120 15 15 0,468 5 20 80 1050x800x1200 PE02 57,93
VS0320006 110/90 100/90 4,3 3,5 220 105 120 15 15 0,503 5 20 80 1050x800x1200 PE02 57,93
VS0320005 110/110 100/100 4,3 4,3 220 105 120 15 15 0,558 5 20 80 1050x800x1200 PE02 57,93
VS0320007 125/50 125/50 4,8 3 220 110 125 15 15 0,550 5 20 80 1210x800x1200 PE02 65,29
VS0320008 125/56 125/56 4,8 3 220 110 125 15 15 0,618 5 20 80 1210x800x1200 PE02 65,29
VS0320009 125/75 125/70 4,8 3 220 110 125 15 15 0,618 5 20 80 1210x800x1200 PE02 65,29
VS0320012 125/90 125/90 4,8 3,5 220 110 125 15 15 0,634 5 20 60 1054x800x1200 PE02 65,29
VS0320011 125/110 125/100 4,8 4,3 220 110 125 15 25 0,667 5 20 40 1045x800x1200 PE02 65,29
VS0320013 125/125 125/125 4,8 4,9 220 110 125 15 25 0,734 5 20 40 950x800x1200 PE02 65,29
VS0318055 160/110 150/100 6,2 4,3 275 137,5 165 50 50 1,172 1 - 35 930x800x1200 PE02 153,41
Derivazione saldata.
