SISTEMI SISTEMI SCARICO SCARICO
GAMMA BLACKFIRE

HTDA braga doppia
87°30’ L 3
D 3 /DN 3 L
87°30’ 87°30’ Z 3
Z 1
D 2 /DN 2
L Z Z L L 1
4 4 2 2
D/DN

COD. D DN L Z L Z L Z L kg HxLxP CL €/pz
1/2/3 1/2/3 1 1 2/4 2/4 3 3
VS0660654 110/50/50 100/50/50 181,5 25 60 63 44 42,5 54 0,274 5 40 120 1000x800x1200 BF02 51,98
VS0660656 Ü 110/110/110 100/100/100 249 64 60 72 52 73 52 0,610 5 20 60 1000x800x1200 BF02 52,52
VS0660659 Ü 125/110/110 125/100/100 252 59 65 79 52 72 56 0,615 5 20 60 1010x800x1200 BF02 114,88
VS0660667 Ü 160/110/110 150/100/100 289 61 84 100 52 81 63 0,889 1 - 45 800x800x1200 BF02 204,99
Ü Pezzo saldato.

Braga curvata doppia L L
87°30’ L 2 3 4
Z Z
D /DN 2 3 D /DN
2
2
3 3
Z
1
L 1
D /DN
1 1
COD. D DN Z L Z L Z L L kg HxLxP CL €/pz
1/2/3 1/2/3 1 1 2 2 3 3 4
VS0662910 90/90/75 90/90/70 57 56 64 56 47 56 53 0,357 15 60 120 955x800x1200 BF02 43,84
VS0662911 90/90/90 90/90/90 57 56 64 56 47 56 56 0,395 12 48 96 955x800x1200 BF02 43,84
VS0662912 110/110/75 100/100/70 69 64 78 66 58 59 52 0,496 5 30 60 955x800x1200 BF02 48,69
VS0662913 110/110/90 100/100/90 69 64 78 66 58 59 56 0,524 5 30 60 955x800x1200 BF02 50,46
VS0662914 110/110/110 100/100/100 69 64 78 66 58 59 59 0,550 5 - 60 955x800x1200 BF02 52,52

HTED braga ad L 3
angolo 87°30’
D 3 /DN 3 L
87°30’ 87°30’ Z 3
Z 1
D 2 /DN 2
L Z Z L L 1
90° 4 4 2 2
D /DN
1 1

COD. D DN Z Z Z L L L L kg HxLxP CL €/pz
1/2/3 1/2/3 1 2/4 3 1 2/4 3
VS0660657 110/110/110 100/100/100 54 77 71 242 63 54 54 0,503 5 20 60 955x800x1200 BF02 54,95
VS0660661 125/110/110 125/100/100 54 77 71 255 71 54 59 0,605 5 20 60 1010x800x1200 BF02 64,25
VS0660662 Ü 160/110/110 150/100/100 68 100 77 290 78 52 67 0,885 1 - 50 800x800x1200 BF02 204,99
Ü Pezzo saldato.

97
