P. 66
D
Elemento di ispezione con tappo. D 2
Inspection element with cap. 1
A
C
H
tot D 3
H
u D
3
D B
OLI ex D.P. Air
Cod. Spessore PPs
Cod. inox D D D D A B C H H
PPs-inox, - PPs-rame
rame/copper 1 2 3 u tot PPs thickness
OL0164023 OL0164023RA 80 100 120 100 35 95 107 178 213 2,1 1
OL0164024 OL0164024RA 100 120 130 130 35 100 122 209 244 2,7 1
Aggiungere fascetta stringitubo per ogni elemento. - Add locking band for each element.
D
Elemento prelievo fumi. 1
Smoke removal element. A
C
H
tot
H D
u int
B
D
Cod. Spessore PPs
Cod. inox D D A B C H H
rame/copper 1 u tot PPs thickness
OL0164025 OL0164025RA 80 100 35 85 106 215 250 2,1 1
OL0164026 OL0164026RA 100 120 35 95 125 215 250 2,7 1
Aggiungere fascetta stringitubo per ogni elemento. - Add locking band for each element.
D
Supporto intermedio. D 2
Intermediate support. 1
H
tot
H u
D
BxC
Cod. Spessore PPs
Cod. inox D D A B C D H H
rame/copper 1 2 u tot PPs thickness
OL0164033 OL0164033RA 80 100 35 180 160 220 215 250 2,1 1
OL0164034 OL0164034RA 100 120 35 220 200 220 215 250 2,7 1
Aggiungere fascetta stringitubo per ogni elemento. - Add locking band for each element.
64 www.oli-world.com
