D
Manicotto femmina - femmina. int
Sleeve female - female. L D int

H tot
H H
u tot
L
D D
est est
Dal Ø 80 al Ø 250 mm Dal Ø 300 al Ø 400 mm
From Ø 80 to Ø 250 mm From Ø 300 to Ø 400 mm
Cod. D D H H L
int est tot u
OL0160600CL  60 61 133 73 60 6
OL0160601 80 81 150 90 60 4
OL0160602 100 101 150 90 60 4
OL0160603 120 121 150 90 60 4
OL0160604 130 131 150 90 60 4
OL0160605 140 141 150 90 60 2
OLI ex S.P. inox
OL0160606 150 151 150 90 60 2
OL0160607 160 161 150 90 60 2
OL0160608 180 181 150 90 60 2
OL0160609 200 201 150 90 60 2
OL0160618 220 221 150 90 60 1
OL0160610 250 251 150 90 60 1
OL0160611CL  300 301 133 73 60 1
OL0160612CL  350 351 133 73 60 1
OL0160613CL  400 401 133 73 60 1
 Aggiungere fascetta stringitubo. - Hose locking band to add. (pag. 115).

Scarico condensa verticale. D int
Vertical condensation discharge. L

70

20
3/4”
Cod. D L
int
OL0160400CL  60 60 6
OL0160401 80 60 4
OL0160402 100 60 4
OL0160403 120 60 4
OL0160404 130 60 4
OL0160405 140 60 2
OL0160406 150 60 2
OL0160407 160 60 2
OL0160408 180 60 2
OL0160409 200 60 2
OL0160418 220 60 1
OL0160410 250 60 1
Aggiungere fascetta stringitubo. - Hose locking band to add. (pag. 115).

